Westgate Mfg. -Outdoor Lighting - LRS with Photocell

DOWNLOADS
  • Aluminium Housing with Powder Coated
  • Includes pre-wired photocell
  • Lumens: 550-1150LM
  • Wattage: 6W & 12W
  • Voltage: 120VAC 60Hz
  • LED: DOB
  • Efficacy: 91LPW
  • Color Rendering Index: CRI ≥ 80

Category: site lighting | solid state lighting | wall-mounted lighting...

MasterFormat: Vehicle and Pedestrian Equipment | Loading Dock Equipment | Loading Dock Lights...


View Product Details From Manufacturer


Westgate Mfg.
2462 E. 28th Street
Vernon, CA 90058
Tel: (877) 805-2252
Fax: (877) 809-2252

customerservice@westgatemfg.com

https://www.westgatemfg.com/

Find a rep/distributor

Request More Info

DOWNLOADS

Related Products

Overview


Outdoor Lighting - LRS with Photocell

Technical Specs

  • Aluminium Housing with Powder Coated
  • Includes pre-wired photocell
  • Lumens: 550-1150LM
  • Wattage: 6W & 12W
  • Voltage: 120VAC 60Hz
  • LED: DOB
  • Efficacy: 91LPW
  • Color Rendering Index: CRI ≥ 80
  • Power Factor: >0.95
  • Operating Temp: -40°F to 104°F
  • Lifespan: 50,000 hours
  • IP Rating: IP65, Wet Locations

Application

  • Ideal for general site lighting, residential houses, doorways, pathways and garages.


See More


Specifications

Variations
Product NameLumensColor TempWattsDimensions
LRS-A-30K-PC1150LM3000K12W9-1/2"L x 7-3/4"W x 4-1/2"D
LRS-A-40K-PC1150LM4000K12W9-1/2"L x 7-3/4"W x 4-1/2"D
LRS-B-30K-PC550LM3000K6W8-1/2"L x 4-1/2"W x 5-3/4"D
LRS-B-40K-PC550LM4000K6W8-1/2"L x 4-1/2"W x 5-3/4"D
LRS-C-30K-D1100LM3000K12W10-5/8"L x 10-5/8"W x 4-3/4"D
LRS-C-40K-D1100LM4000K12W10-5/8"L x 10-5/8"W x 4-3/4"D
LRS-D-30K-D1100LM3000K12W10-1/4"L x 10-1/4"W x 5"D
LRS-D-40K-D1100LM4000K12W10-1/4"L x 10-1/4"W x 5"D
