Overview


Umbriano Pavers

The natural look and feel of granite.

The zero bevel edge and granite-like appearance of Umbriano make it a popular choice for sleek, modern landscape paving projects. It’s unique, mottled surface is achieved with ColorFusion™ Technology that randomly disperses rich color and granite particles. This creates a natural look with a non-slip texture. As a result, this product is ideal for pool decks and entryways. Umbriano is factory sealed during the manufacturing process with EasyClean™, an integral surface protection from stains. Umbriano’s features make it ideal for use in high traffic commercial and residential projects.

Features

Applications

Borders & Accents

Commercial Vehicular

Pedestrian

Residential Vehicular

Roof Deck

Roof Deck Pedestal

Technologies

ColorFusion Technology Available

EasyClean Stain Resistance Available

An integral surface protection that allows for easier cleanup of spills when they happen, and before a stain can develop.

Custom Colors

May be available for this product. Minimum quantities will apply.

EnduraColor Facemix Technology

EnduraColor products are manufactured in a two-step process which combines a base of coarser aggregates for a stronger foundation, with concentrated color and wear-resistant finer aggregates on top. EnduraColor products are highly resistant to fading because the top layer prevents large, lighter color aggregates from showing through.

Surface Texture

Mottled

Smooth - Zero Bevel

TECHNICAL INFORMATION

ASTM C 936 Standard Specifications for Solid Concrete Interlocking Paving Units

Conforms to:

  • C140 for Absorption and Compressive Strength > 8,000 PSI
  • C67 for Freeze-thaw Durability
  • C418 for Abrasion Durability

Unilock standards exceed 8,500 PSI for Umbriano products with:

  • 4% absorption avg.
  • 5% absorption max.
  • Dimensional Accuracy +/- 3/64”

Meets the U.S. Architectural & Transportation Barrier Compliance Board Slip-Resistance Surfaces Advisory Guidelines

LEED INFORMATION

Materials and Resources: LEED V4:

Building Product Disclosure and Optimization

Sourcing of Raw Materials - Sourcing of Raw Materials and Extraction • 1 point

Sourcing of Raw Materials - Leadership Extraction Practices • 1 point

Material Ingredient Reporting - Material Ingredient Reporting • 1 point

Material Ingredient Reporting - Material Ingredient Optimization • 1 point

Environmental Product Declaration • 1 point

Note: Product offerings and availability may vary by region. Connect with your local Unilock representative for more information.


See More


Specifications

Packaging
UnitSqFt PerSqFt PerSqFt PerPer BundleSoldier LnFt PerSoldier LnFt PerSailor LnFt PerSailor LnFt PerUnits PerUnits PerLbs PerLbs Per
Stones & BundlingThicknessBundleLayerStoneLayersSqFtBundleSqFtBundleSqFtBundleLayersBundle
36 x 364" (10cm)43.598.72551994
18 x 36"4" (10cm)43.598.755101994
Random Bundle 8cm73.2210.4670.9874.4563832680
Large Rectangle3-1/8" (8cm)2.091.751.1624.80.4814
Square3-1/8" (8cm)1.41.181.180.7221
Small Rectangle3-1/8" (8cm)0.71.1670.591.4321
7"x14"3-1/8" (8cm)73.2410.460.69871.18620.591241.431053832680
24"x24"2-3/4" (7cm)627.753.87581.9731.51.9731.50.26162582062
12"x24"2-3/4" (7cm)9311.631.9481.9747.20.9894.50.52483933142
16"x16"2-3/4" (7cm)82.6710.331.7281.31631.31630.58483502797
8"x16"2-3/4" (7cm)82.6710.330.8681.31630.661261.16963432746
Hex2 3/4" (7cm)73.922450
XL Unit2 3/8"94.210.475.239182584
Random Bundle 6cm94.1410.4791.3631.167722872584
Large Rectangle2-3/8" (6cm)2.091.7681.1670.4818
Small Rectangle2-3/8" (6cm)0.71.1831.91.4327
Square2-3/8" (6cm)1.3951.181.180.69827
