Unilock -Series Pavers

DOWNLOADS

Perfect for driveways, walkways and a whole lot more.

Series’ specialized manufacturing process creates a striking visual effect with the surface granite particles and also results in an extremely durable paver.


Category: driveway pavers | street paving | vehicular pavers...

MasterFormat: Roof Pavers | Bases, Ballasts, and Paving | Unit Paving



Unilock
Boston, Buffalo, Chicago, Cleveland, Detroit,
Milwaukee, New York
Toronto, ON M9C 5J5
Tel: (800) 864-5625

elaine.willis@unilock.com

https://commercial.unilock.com/

Find a rep/distributor

Request More Info

DOWNLOADS

Related Products

Overview


Series Pavers

Perfect for driveways, walkways and a whole lot more.

Series’ specialized manufacturing process creates a striking visual effect with the surface granite particles and also results in an extremely durable paver. The aggregate surface is pressed into the stone surface simultaneously with the body of the stone in a single process and not in layers. The resulting surface becomes an integral part of the paver itself, giving you long-term wear and structural performance. Ideal for offices, commercial retail plazas and institutions. Ask about the custom opportunities with this product.

Features

Applications

Borders & Accents

Commercial Vehicular

Pedestrian

Residential Vehicular

Roof Deck

Custom Colors

May be available for this product. Minimum quantities will apply.

Surface Texture

CustomizableExposed Granite

EnduraColor Facemix Technology

EnduraColor products are manufactured in a two-step process which combines a base of coarser aggregates for a stronger foundation, with concentrated color and wear-resistant finer aggregates on top. EnduraColor products are highly resistant to fading because the top layer prevents large, lighter color aggregates from showing through.

Special Order

Minimum quantities apply

TECHNICAL INFORMATION

ASTM C 936 Standard Specifications for Solid Concrete Interlocking Paving Units

Conforms to:

  • C140 for Absorption and Compressive Strength > 8,000 PSI
  • C67 for Freeze-thaw Durability
  • C418 for Abrasion Durability

Unilock standards exceed 8,500 PSI for Series™ products with:

  • 4% absorption avg.
  • 5% absorption max.
  • Dimensional Accuracy +/- 3/64”

Meets the U.S. Architectural & Transportation Barrier Compliance Board Slip-Resistance Surfaces Advisory Guidelines

LEED INFORMATION

Materials & Resources: LEED V4:

Building Product Disclosure and Optimization

Sourcing of Raw Materials - Sourcing of Raw Materials and Extraction • 1 point

Sourcing of Raw Materials - Leadership Extraction Practices • 1 point

Material Ingredient Reporting - Material Ingredient Reporting • 1 point

Material Ingredient Reporting - Material Ingredient Optimization • 1 point

Environmental Product Declaration • 1 point

Note: Product offerings and availability may vary by region. Connect with your local Unilock representative for more information.


See More


Specifications

Packaging
UnitSqFt PerSqFt PerSqFt PerPer BundleSoldier LnFt PerSoldier LnFt PerSailor LnFt PerSailor LnFt PerUnits PerUnits PerLbs PerLbs Per
Stones & BundlingThicknessBundleLayerStoneLayersSqFtBundleSqFtBundleSqFtBundleLayersBundle
8" x 24"4" (10cm)51.6710.331.29251.96926.20.65678.70.77404782391
4" x 12"4" (10cm)58.1311.630.32350.98459.10.328177.23.101805322659
Random Bundle 8cm73.2410.461.30870.98574.40.77563832680
Large Rectangle3-1/8" (8cm)2.0891.18124.80.4814
Small Rectangle3-1/8" (8cm)0.6980.59124.81.4321
Square3-1/8" (8cm)1.3951.18124.80.7221
7" x 14"3 1/8" (8cm)73.2410.460.69871.181620.5911241.431053832680
8"x16"2-3/4" (7cm)82.6710.330.86181.312630.6561261.16963432746
8"x8"2-3/4" (7cm)82.6710.330.46180.6561260.6561262.321923312647
4"x8"2-3/4" (7cm)94.411.80.21980.667141.70.334283.34.574323773019
