Promenade Plank Pavers

Customize the appearance of your project

The long and narrow design of Promenade™ Plank Paver facilitates a linear laying pattern resulting in a finished and sleek appearance to complement current architectural design trends. Manufactured using the most advanced techniques and technologies EnduraColor™, they are ideal for the most demanding commercial applications. The Promenade Plank Paver series is available in a variety of Unilock Architectural finishes such as Umbriano®, Il Campo®, Series™ and Smooth Premier.

Features

Applications

Borders & Accents

Commercial Vehicular

Pedestrian

Residential Vehicular

Surface Texture

BrushedCustomizableExposed GraniteSmooth PremierStandard

Custom Colors

May be available for this product. Minimum quantities will apply.

EnduraColor Facemix Technology

EnduraColor products are manufactured in a two-step process which combines a base of coarser aggregates for a stronger foundation, with concentrated color and wear-resistant finer aggregates on top. EnduraColor products are highly resistant to fading because the top layer prevents large, lighter color aggregates from showing through.

Special Order

Minimum quantities apply

TECHNICAL INFORMATION

ASTM C 936 Standard Specifications for Solid Concrete Interlocking Paving Units

Conforms to:

  • C140 for Absorption and Compressive Strength > 8,000 PSI
  • C67 for Freeze-thaw Durability
  • C418 for Abrasion Durability

Unilock standards exceed 8,500 PSI for Promenade™ products with:

  • 4% absorption avg.
  • 5% absorption max.
  • Dimensional Accuracy +/- 3/64”

Meets the U.S. Architectural & Transportation Barrier Compliance Board Slip-Resistance Surfaces Advisory Guidelines

LEED INFORMATION

Materials and Resources: LEED V4:

Building Product Disclosure and Optimization

Sourcing of Raw Materials - Sourcing of Raw Materials and Extraction • 1 point

Sourcing of Raw Materials - Leadership Extraction Practices • 1 point

Material Ingredient Reporting - Material Ingredient Reporting • 1 point

Material Ingredient Reporting - Material Ingredient Optimization • 1 point

Environmental Product Declaration • 1 point

Note: Product offerings and availability may vary by region. Connect with your local Unilock representative for more information.


See More


Specifications

Packaging
UnitSqFt PerSqFt PerSqFt PerPer BundleSoldier LnFt PerSoldier LnFt PerSailor LnFt PerSailor LnFt PerUnits PerUnits PerLbs PerLbs Per
Stones & BundlingThicknessBundleLayerStoneLayersSqFtBundleSqFtBundleSqFtBundleLayersBundle
8" x 24"3-7/8" (10cm)51.6710.331.2951.9726.20.6678.70.77404782391
4" x 16"3-7/8" (10cm)51.6710.330.4351.3139.40.33157.72.321204882440
4" x 12"3-7/8" (10cm)58.1311.630.3250.9859.10.33177.23.11805322659
