Unilock -Il Campo Pavers

DOWNLOADS

With its uniquely textured surface, this remarkable paver is the ideal solution.

Created with technology that is exclusive to Unilock, the etched lines on the surface of Il Campo make it a richly detailed, striking choice for virtually any application.


Category: concrete pavers | pavement | roadway pavings...

MasterFormat: Roof Pavers | Bases, Ballasts, and Paving | Unit Paving...



Unilock
Boston, Buffalo, Chicago, Cleveland, Detroit,
Milwaukee, New York
Toronto, ON M9C 5J5
Tel: (800) 864-5625

elaine.willis@unilock.com

https://commercial.unilock.com/

Find a rep/distributor

Request More Info

DOWNLOADS

Related Products

Overview


Il Campo Pavers

With its uniquely textured surface, this remarkable paver is the ideal solution.

Created with technology that is exclusive to Unilock, the etched lines on the surface of Il Campo make it a richly detailed, striking choice for virtually any application. Its texture is inviting and unlike any other paver you can buy, while being durable and colourfast.

Features

Applications

Borders & Accents

Commercial Vehicular

Pedestrian

Residential Vehicular

Roof Deck

Surface Texture

BrushedCustomizable

Custom Colors

May be available for this product. Minimum quantities will apply.

EnduraColor Facemix Technology

EnduraColor products are manufactured in a two-step process which combines a base of coarser aggregates for a stronger foundation, with concentrated color and wear-resistant finer aggregates on top. EnduraColor products are highly resistant to fading because the top layer prevents large, lighter color aggregates from showing through.

TECHNICAL INFORMATION

ASTM C 936 Standard Specifications for Solid Concrete Interlocking Paving Units

Conforms to:

  • C140 for Absorption and Compressive Strength > 8,000 PSI
  • C67 for Freeze-thaw Durability
  • C418 for Abrasion Durability

Unilock standards exceed 8,500 PSI for Il Campo® products with:

  • 4% absorption avg.
  • 5% absorption max.
  • Dimensional Accuracy +/- 3/64″

Typical pour-in-place concrete ranges from approximately 2,500 to 5,500 PSI after 28 days.

Meets the U.S. Architectural & Transportation Barrier Compliance Board Slip-Resistance Surfaces Advisory Guidelines*

LEED INFORMATION

Materials & Resources: LEED V4:

Building Product Disclosure and Optimization

Sourcing of Raw Materials - Sourcing of Raw Materials and Extraction • 1 point

Sourcing of Raw Materials - Leadership Extraction Practices • 1 point

Material Ingredient Reporting - Material Ingredient Reporting • 1 point

Material Ingredient Reporting - Material Ingredient Optimization • 1 point

Environmental Product Declaration • 1 point


See More


Specifications

Packaging
UnitSqFt PerSqFt PerSqFt PerPer BundleSoldier LnFt PerSoldier LnFt PerSailor LnFt PerSailor LnFt PerUnits PerUnits PerLbs PerLbs Per
Stones & BundlingThicknessBundleLayerStoneLayersSqFtBundleSqFtBundleSqFtBundleLayersBundle
4 x 82-3/4" (7cm)94.411.800.2280.667141.80.334283.64.574323773021
8 x 162-3/4" (7cm)82.6710.330.8681.31630.661261.16963432746
4 x 124" (10cm)58.1311.630.3250.9859.10.33177.23.11805322659
8 x 244" (10cm)51.6710.331.2951.9726.20.6678.7404782391
