Permeable, heavy duty unit pavers have been so ‘on-trend’. Eco-Line can be mechanically installed at a rate of 6,000-7,000 sq.ft. per machine, per day, with minimal labor.


Category: concrete pavers | pavement | roadway pavings...

MasterFormat: Bases, Ballasts, and Paving | Unit Paving | Precast Concrete Unit Paving



Unilock
Boston, Buffalo, Chicago, Cleveland, Detroit,
Milwaukee, New York
Toronto, ON M9C 5J5
Tel: (800) 864-5625

elaine.willis@unilock.com

https://commercial.unilock.com/

Find a rep/distributor

Request More Info

DOWNLOADS

Related Products

Overview


Eco-Line Pavers

Permeable, heavy duty unit pavers have been so ‘on-trend’. Eco-Line can be mechanically installed at a rate of 6,000-7,000 sq.ft. per machine, per day, with minimal labor. As a very competitive permeable pavement that can be installed even in adverse weather conditions, Eco-Line is not only beautiful, but cost effective.

Features

Applications

Commercial Vehicular

Pedestrian

Permeable

Residential Vehicular

Custom Colors

May be available for this product. Minimum quantities will apply.

Surface Texture

Customizable

EnduraColor Facemix Technology

EnduraColor products are manufactured in a two-step process which combines a base of coarser aggregates for a stronger foundation, with concentrated color and wear-resistant finer aggregates on top. EnduraColor products are highly resistant to fading because the top layer prevents large, lighter color aggregates from showing through.

Special Order

Minimum quantities apply

TECHNICAL INFORMATION

ASTM C 936 Standard Specifications for Solid Concrete Interlocking Paving Units

Conforms to:

  • C140 for Absorption and Compressive Strength > 8,000 PSI
  • C67 for Freeze-thaw Durability
  • C418 for Abrasion Durability

Unilock standards exceed 8,500 PSI for Eco-Line® products with:

  • 4% absorption avg.
  • 5% absorption max.
  • Dimensional Accuracy +/- 3/64″

Meets the U.S. Architectural & Transportation Barrier Compliance Board Slip-Resistance Surfaces Advisory Guidelines

LEED INFORMATION

Rainwater Management: LEED V4:

  • Up to three points can be achieved for retaining rain water onsite based on the percentile kept
  • 85% (zero lot line projects only) - 3 points, 95% - 2 points and 98% - 3 points. (All except Healthcare - subtract one point) See LEED v4 for more specific project details.

Materials and Resources: LEED V4:

Building Product Disclosure and Optimization

Sourcing of Raw Materials - Sourcing of Raw Materials and Extraction • 1 point

Sourcing of Raw Materials - Leadership Extraction Practices • 1 point

Material Ingredient Reporting - Material Ingredient Reporting • 1 point

Material Ingredient Reporting - Material Ingredient Optimization • 1 point

Environmental Product Declaration • 1 point


See More


Specifications

Packaging
UnitSqFt PerSqFt PerSqFt PerPer BundleUnits PerUnits PerLbs PerLbs Per
Stones & BundlingThicknessBundleLayerStoneLayersSqFtBundleLayersBundle
Random Bundle66.211.0362.91925043027
Large 11.43-7/8" (10cm)0.392.5724
Large 8.43-7/8" (10cm)0.293.4924
Medium 11.43-7/8" (10cm)0.342.9424
Medium 8.43-7/8" (10cm)0.253.9924
Small 11.43-7/8" (10cm)0.293.4424
Small 8.43-7/8" (10cm)0.214.6724
XL 11.43-7/8" (10cm)0.442.2824
XL 8.43-7/8" (10cm)0.323.124
