Unilock -DuraHold2 Retaining Wall

DOWNLOADS

DuraHold 2. When speed and efficiency count.

DuraHold 2 is similar to DuraHold in appearance, but is just over half the size, making it economical for low walls. Concrete tie-backs or geogrid reinforcement gives this wall various engineering options.


Category: earth retaining products | landscaping products | retaining walls...

MasterFormat: Unit Masonry | Concrete Unit Masonry | Manufactured Masonry...



Unilock
Boston, Buffalo, Chicago, Cleveland, Detroit,
Milwaukee, New York
Toronto, ON M9C 5J5
Tel: (800) 864-5625

elaine.willis@unilock.com

https://commercial.unilock.com/

Find a rep/distributor

Request More Info

DOWNLOADS

Related Products

Overview


DuraHold2 Retaining Wall

DuraHold 2. When speed and efficiency count.

DuraHold 2 is similar to DuraHold in appearance, but is just over half the size, making it economical for low walls. Concrete tie-backs or geogrid reinforcement gives this wall various engineering options.

Features

Custom Colors

May be available for this product. Minimum quantities will apply.

Applications

Engineered Retaining Wall

Garden Wall

Retaining Wall

Seat Wall

Special Order

Minimum quantities apply

Surface Texture

Standard

TECHNICAL INFORMATION

ASTM C 1372 Standard Specifications for Dry-Cast Segmental Retaining Wall Units

Conforms to:

  • C140 for Absorption and Compressive Strength > 3000 PSI
  • C1262 for Freeze Thaw Durability <1% mass loss
  • C1372 Overall dimensional variations permissable for width, height and length ± 1/8” (±3.2mm)

Unilock standards exceed 6,000 PSI for Durahold2® products with:

  • 4% absorption avg.
  • 5% absorption max.
  • Dimensional Accuracy +/- 5/64” (±2.00mm)

Meets the U.S. Architectural & Transportation Barrier Compliance Board Slip-Resistance Surfaces Advisory Guidelines*

LEED INFORMATION

Materials & Resources: LEED V4:

Building Product Disclosure and Optimization

Sourcing of Raw Materials - Sourcing of Raw Materials and Extraction • 1 point

Sourcing of Raw Materials - Leadership Extraction Practices • 1 point

Material Ingredient Reporting - Material Ingredient Reporting • 1 point

Material Ingredient Reporting - Material Ingredient Optimization • 1 point

Environmental Product Declaration • 1 point

Note: Product offerings and availability may vary by region. Connect with your local Unilock representative for more information.


See More


Specifications

Packaging
Face Feet PerFace Feet PerLinear Feet PerLinear Feet PerUnits PerUnits PerLbs PerLbs Per
Stones & BundlingBundleUnitBundleUnitBundleFace FeetUnitBundle
Wall Standard24.16.02424.16.02440.179383752
Coping 7224.16.02424.16.024 40.178843536
Coping Closed End 7224.16.02424.16.02440.178843536
Wall Tieback4.681.1740.869383752
Corner 90°16.674.16740.244601840
