Unilock -Beacon Hill Smooth Pavers

DOWNLOADS

Beacon Hill Smooth offers a smooth surface texture for a sleek, modern look with a contemporary color palette.


Category: concrete pavers | pedestrian walkways | walkway pavers...

MasterFormat: Roof Pavers | Bases, Ballasts, and Paving | Unit Paving...



Unilock
Boston, Buffalo, Chicago, Cleveland, Detroit,
Milwaukee, New York
Toronto, ON M9C 5J5
Tel: (800) 864-5625

elaine.willis@unilock.com

https://commercial.unilock.com/

Find a rep/distributor

Request More Info

DOWNLOADS

Related Products

Overview


Beacon Hill Smooth Pavers

Beacon Hill Smooth offers a smooth surface texture for a sleek, modern look with a contemporary color palette. Available in two thicknesses, this product can be used for pedestrian and vehicular applications while offering the refined surface textures and long-lasting color benefits of Enduracolor technology.

Features

Applications

Pedestrian

Roof Deck

Custom Colors

May be available for this product. Minimum quantities will apply.

EnduraColor Facemix Technology

EnduraColor products are manufactured in a two-step process which combines a base of coarser aggregates for a stronger foundation, with concentrated color and wear-resistant finer aggregates on top. EnduraColor products are highly resistant to fading because the top layer prevents large, lighter color aggregates from showing through.

Surface Texture

Smooth Premier

TECHNICAL INFORMATION

ASTM C 936 Standard Specifications for Solid Concrete Interlocking Paving Units

Conforms to:

  • C140 for Absorption and Compressive Strength > 8,000 PSI
  • C67 for Freeze-thaw Durability
  • C418 for Abrasion Durability

Unilock standards exceed 8,500 PSI for Beacon Hill Smooth™ products with:

  • 4% absorption avg.
  • 5% absorption max.
  • Dimensional Accuracy +/- 3/64”

Meets the U.S. Architectural & Transportation Barrier Compliance Board Slip-Resistance Surfaces Advisory Guidelines

LEED INFORMATION

Materials & Resources: LEED V4:

Building Product Disclosure and Optimization

Sourcing of Raw Materials - Sourcing of Raw Materials and Extraction • 1 point

Sourcing of Raw Materials - Leadership Extraction Practices • 1 point

Material Ingredient Reporting - Material Ingredient Reporting • 1 point

Material Ingredient Reporting - Material Ingredient Optimization • 1 point

Environmental Product Declaration • 1 point

Note: Product offerings and availability may vary by region. Connect with your local Unilock representative for more information.


See More


Specifications

Packaging
UnitSqFt PerSqFt PerSqFt PerPer BundleSoldier LnFt PerSoldier LnFt PerSailor LnFt PerSailor LnFt PerUnits PerUnits PerLbs PerLbs Per
Stones & BundlingThicknessBundleLayerStoneLayersSqFtBundleSqFtBundleSqFtBundleLayersBundle
Random Bundle 6cm2-3/8" (6cm)94.1410.4690.76722872584
Large Rectangle2-3/8" (6cm)2.090.4818
Small Rectangle2-3/8" (6cm)0.71.4327
Square2-3/8" (6cm)1.40.7227
Small Rectangle 6cm (Smooth Only)2-3/8" (6cm)94.210.470.791.1778.750.59157.51.431352872584
Slab2-3/8" (6cm)75.338.374.1992.3331.51.75420.24182302067
Random Bundle 8cm3-1/8" (8cm)73.2210.4670.77563832680
Large Rectangle3-1/8" (8cm)2.090.4814
Small Rectangle3-1/8" (8cm)0.71.4321
Square3-1/8" (8cm)1.40.7221
Small Rectangle 8cm (Smooth Only)3-1/8" (8cm)73.2410.460.771.1778.750.58157.51.431053832680
