Overview


Structural Panel Concrete Foundation Wall

Designed to be fastened to load-bearing cold-formed steel studs for a nonrotting, noncombustible high-strength foundation wall.

Cured-in-factory panel ideal for use in applications such as full-height basements, storm shelters, crawl spaces and cellars Structural Panel Concrete Foundation Wall is mechnically fastened to cold-formed-steel or wood-studs to form the structural foundation wall system in the construction of light-framed buildings up to three stories tall. This panel is the answer to a structurally stable, inorganic product that offers easy foundation installation and solves existing deteriorating brick foundation issues.

Main Features

A fast alternative to other foundation wall materials such as CMU and poured concrete or existing deteriorated plywood as a residential foundation wall.

  • Faster: No form work, no pouring, no setting, no curing

  • Nonrotting, termite-, mold- and moisture-resistant

  • Strong, durable concrete panel

  • Dimensionally stable, panel will not buckle or warp like wood sheathing

  • Easy installation:circular saw for cutting, screws for fastening

  • 3/4" panels provide thinner profile for foundation

  • Noncombustible-meets the criteria of ASTM E136-16 and CAN S114

  • Designed for full-height basements

  • Made in the USA
