Overview


Gusset Plates

Gusset plates are available in all structural thicknesses, widths, and lengths up to 10 feet. They may be used for truss construction, ends of diagonal strap X bracing, anchors at the base of walls, force transfer locations at floor-wall or floor-roof intersections, or other locations where flat steel is required.

Product Data and Ordering Information:

Available lengths: from 1” to 120”
Available widths: from 1” to 48”
Available Coatings: G60, G90

ASTM and Code Standards:

International Building Code (IBC) 2006 - 2018
Sheet Steel: ASTM A1003 and ASTM A653
Galvanized Coating: ASTM A653
Members and Tolerances: ASTM C955
Meets ASTM C1007 when installed properly in structure
3rd Party Certification: Manufacturing verified and inspected by Home Innovation Research Labs, Inc.
