Specified Technologies, Inc. -CP Connection Protection

DOWNLOADS

SpecSeal Connection Protection is the go to solution for protecting underside mounted mullion brackets in curtain wall construction. Custom sized to your style of bracket, Connection Protection installs quickly with common job site tools.


Category: building perimeter firestopping | glazed curtain walls | mullion curtain walls...

MasterFormat: Firestopping | Building Perimeter Firestopping | Entrances, Storefronts, and Curtain Walls...


View Product Details From Manufacturer


Specified Technologies, Inc.
210 Evans Way
Somerville, NJ 08876
Tel: (800) 992-1180
Fax: (908) 526-9623

customerservice@stifirestop.com

https://www.stifirestop.com/

Find a rep/distributor

Request More Info

DOWNLOADS

Related Products

Overview


CP Connection Protection

SpecSeal Connection Protection is the go to solution for protecting underside mounted mullion brackets in curtain wall construction. Custom sized to your style of bracket, Connection Protection installs quickly with common job site tools. SpecSeal Connection Protection is the only proven method for protecting exposed mullion mounting brackets, ensuring their integrity and performance under fire exposure.

Features

  • Eliminate Mineral wool wraps and Spray-Applied Fire Resistive Materials
  • Professional fit and finished appearance
  • No construction debris or waste
  • Installs quickly with concrete screws, or powder actuated fasteners


See More


Specifications

Physical Properties
PropertyValue
Shell CompositionRefractory Ceramic Fiber (RCF) (Consult Safety Data Sheet)
WeightLess than 6.5 lbs. (2.94 kg)
Maximum Use Temperature2,300°F (1,260°C)
Melting Point3260°F (1793°C)
Density (lb./cu ft)14 to 18 lb./cu ft (0.22 to 0.29 g/ccm)
Overall Dimensions16" x 20"x 5" (406 mm x 508 mm x 127 mm)
Maximum Anchor Dimension (Including Bolt Height)11" x 13" x 3" (280 mm x 330 mm x 76 mm)
Intumescent Expansion At320°F (160°C)
Density10 pcf (160 kg/cu m)
Non-CombustibleYes
IARC ContentGroup 3: Not classifiable as carcinogenic to humans (Bio soluble fiber)
Recycle Content100%
Fiber Melting Temperature2,012°F (1,100°C)
Fiber Insert
PropertyValue
Thickness1.0"(25.4 mm)
Ordering Information
Catalog NumberUPC NumberDescription
CP100730573100004Connecton Protection - Under Mount Curtain Wall Anchor Protector
