Overview


Glydea Motorized Drapery System

We offer Quiet Motorized Drapery Tracks for many sizes and applications, including custom bends and recessed tracks. Advanced options such as tandem motors and inverted (hidden) motors are also offered.

Glydea Motorized Drapery System Features

Mechanism

  • Direct Drive - 120V AC motors from 48” to 432”

  • Tandem (Dual) Motors for large tracks

Motor Controls
  • Dry Contact - DCT

  • InfraRed - IR

  • RTS - Simple Radio

  • RS485 - Serial (RS232 adaptable)

  • ZWave - Mesh Network Radio

  • Zigbee - Mesh Network Radio

  • Wired - 4-Wire AC Switching

  • Automation and Smartphone

Styles
  • Pinch Pleat (Standard)

  • Ripplefold

  • Accordia

Track
  • Finish - White standard - Custom finishes available

Operation
  • Straight

  • Curved - 90 degree

  • Curved - Continuous or Custom

Draw
  • Center

  • One way

  • Off set

Advancements
  • Soft Start/Stop

  • Manual Operation

  • Automatic Limits on End Stop

  • Intermediate Position

  • Touch/Pull to Start

  • Speed Control

  • Hidden Motor Power Cord

Installation Features
  • Setting via Motor Buttons

  • Setting via Dry Contact

  • LED Indicators

  • Motor Direction Change

  • Factory Reset

  • Inverted Mounting Option

Specifications
  • Power - 110VAC 50/60 Hz 1A 120W

  • Speed - 4.9"/s to 7.86"/s

  • Data Port - RJ12

  • Noise - <44 dBA

  • Certifications - c TUV us, CE

  • Max # of Splices - 2

  • Min. Bend Radius - 12"

  • Min. Curve Radius - 118"

  • Single Motor Max. Weight - 132 lbs.

  • Tandem Motor Max. Weight - 264 lbs.


See More


Specifications

One Way Track Details
Center Draw Track Details
Mounting and Bracketing Options
One Touch Ceiling BracketOne Touch Ceiling Bracket Installed
Swivel Ceiling BracketSwivel Ceiling Bracket Installed
Adjustable Wall Mount BracketDouble Adjustable Wall Mount Bracket
