SOSS Door Hardware -Barrel Hinge

SOSS® Invisible Barrel Hinges are made of solid brass with brass links. They are easily installed. SOSS® Invisible Barrel Hinges are totally invisible from either side when the door is closed.

Category: hinges | hinges | residential door hinges...

MasterFormat: Architectural Woodwork | Cabinet and Drawer Hardware | Door Hardware...

View Product Details From Manufacturer

SOSS Door Hardware
One Coreway Drive
Pioneer, OH 43554
Tel: (419) 737-2324
Fax: (419) 737-2130

Related Products

Overview

Barrel Hinge

SOSS® Invisible Barrel Hinges are made of solid brass with brass links. They are easily installed. SOSS® Invisible Barrel Hinges are totally invisible from either side when the door is closed. SOSS® Invisible Barrel Hinges are not recommended for vertical or load bearing application.

Material Thickness

1/2"
5/8"
3/4"
7/8"
1-1/8"
1-1/4"

See More

See Less

Specifications

Dimensions

Part #	Min. Door Thickness	Drill Bit (mm)	Drill Bit (in.)	A	B	C	D min.	E max.	Wood Screw
BH085	7⁄16"	8.2 mm	Letter “O”	8.18	9.9	11.6	1.9	0.8	#3x3⁄8"
BH104	1⁄2"	10 mm	25⁄64"	10	11.5	15.7	2	1.8	#3x3/8"
BH124	5⁄8"	12 mm	15⁄32"	12	13.3	19	2.7	2.1	#4x1⁄2"
BH144	3⁄4"	14 mm	35⁄64"	14	15.5	23	3	3	#6x1⁄2"
BH164	7⁄8"	16 mm	5⁄8"	16	16.5	23.5	3	2.3	#6x5/8"
BH184	11⁄8"	18 mm	45⁄64"	18	18	27	3	3	#6x3⁄4"
BH244	11⁄4"	24 mm	15⁄16"	24	24.9	35.1	4.1	3.5	#10x11/4"
