Ceiling Baffles - SAS500

SAS500 acoustic baffles offer a visually engaging alternative to suspended acoustic ceiling systems, ideal for exposed soffit areas.

Available in numerous colours and sizes, the baffles can be suspended at a range of heights and angles for further visual interest.

SAS500 has a lighting option which is ideal for open plan spaces.

Summary

SAS500 is a linear acoustic baffle system directly suspended from the soffit for exposed applications. Baffles can be suspended as individual modules or continual, unbroken runs.

• Enhanced acoustic performance due to double faced panels
• Ideal acoustic treatment for open, exposed interiors and thermal mass cooling
• Pre-assembled modules for individual baffles
• Part-assembled for long runs due to installation requirements
• Long runs quick and simple to set out
• Complete access to services due to nature of system
• Baffles can be suspended in varying heights and angles for visual interest
• Different sizes, shapes and colours of baffles can be combined to create visually arresting interiors
• Minimum 25 year product life expectancy

Suspension System

• Primary Grid
• Threaded Rod
• Cable Hanger

System Weight and Size

System weight is entirely dependent on module dimensions and acoustic treatment.

STANDARD MODULE LENGTHS (MM)

• 1200
• 1500
• 1800

STANDARD MODULE DEPTHS (MM)

MINIMUM DEPTH (MM)

• 100

MAXIMUM DEPTH (MM)

• 500

Minimum and maximum depths are confined to the manufacturing methods of System 500. Deeper modules are possible, but require different methods of manufacturing.

Standard Finsih

• Coating - Polyester powder coat
• Colour - RAL 9010 (Pure White)

• Available in full range of standard RAL colours
• Anti-Microbial Coating

Standard Baffle Size

• Square
• Rectangle

Bespoke baffle shapes are possible. If your specification requires complex shapes, please contact our technical design team for more information.

Perforation

SAS500 modules can be supplied with any standard SAS perforation pattern.

Acoustic Treatments

• Acoustic pad as standard

(50mm deep, 45Kg density mineral-wool pad with black tissue face).

Other acoustic treatments are available, depending on project requirement. Please contact our technical department for more information.

Integration

SAS500 baffles can be manufactured with integrated, traditional and fluorescent LED lighting.

Cross Ventilation

Ceiling mounted acoustic baffles provide acoustic absorption whilst allowing the concrete soffit to be fully exposed for energy-efficient natural cross ventilation cooling.

Working In Conjunction with a Suspended Ceiling

Baffles provide high levels of acoustic absorption. For demanding environments they can be installed in conjunction with a suspended metal ceiling.

Solar Shading

When acoustic baffles are suspended in large atria they can also offer the dual function of acting as solar shading by diffusing natural daylight from the reflective surface.
