SAFB™ Mineral Wool Sound Attenuation Fire Blankets

SAFB Mineral Wool Sound Attenuation Fire Blankets

  • Exceptional sound and noise absorption
  • Excellent Thermal Performance (R-Value of 3.7 per inch)
  • Adds STC value to wall and floor-ceiling assemblies
  • Provides life saving fire protection in rated assemblies
  • Fire resistant to temperatures above 2,000°F (1,093°C)
  • Conserves energy, reduces greenhouse gas emissions
  • Mold Resistant

Thermafiber® SAFB (Sound Attenuation Fire Blankets)

Description:

THERMAFIBER Sound Attenuation Fire Blankets (SAFB) are mineral wool batts designed to stop sound, save energy, and provide life saving fire protection. These products are noncombustible, moisture-resistant, noncorrosive, nondeteriorating, mildew-proof and vermin- proof. Thermafiber® SAFBs provide acoustical control, thermal insulation, and fire protection in many different UL fire rated wall and floor-ceiling assemblies. SAFBs resist temperatures over 2000ºF. SAFBs add STCs to wall and floor-ceiling assemblies. SAFBs can be installed in both steel stud and wood stud construction. See Thermafiber’s SAFB Brochure (TF885) for more detail on STC and fire ratings for multiple wall and floor-ceiling assemblies.

Product Options:

Recycled Content Options¹:

EPA Choice Fiber (US Government Buildings)................Minimum 75%

Standard Fiber............................................................................70%

¹Recycled content options other than Standard must be specified at time of order.

  • Standard SAFB
  • Creased SAFB – Made 1” wider than standard stud spacing to bow in the stud cavity for increased sound absorption.

Installation:

  • Interior Stud Cavity – Friction fit SAFBs securely between studs. Butt ends of blankets closely together and fill all voids.
  • Creased SAFB – Bow the blankets slightly to fit into stud cavity. Slit the blankets vertically 1” deep with a utility knife.
  • Floor-Ceiling – Friction fit SAFBs securely between floor joists.
  • Ceiling Overlayment – Lay SAFBs over ceiling panels extending 48” beyond all partitions. Tightly fit around all hangers, obstructions, and penetrations.


Standard Sizes:


Thickness*
Widths**
Lengths**
SAFB 2.5 pcf
1½”- 7”
15¼”, 16”, 17”, 23”, 24”, 25”
48”
SAFB 4.0 pcf**
1”
15¼”, 16”, 17”, 23”, 24”, 25”
48”
Tolerances
+1/4” - 1/8”
± 1/8”
±1/2"
*Thicknesses are available in 1/2” increments. Custom sizes are available upon request.
**Non-Standard 4.0 pcf is available in thicknesses of 1 ½” – 7” upon special request
***15 ¼” and 23” are recommended widths for wood stud construction


Technical Data:


Tested to ASTM E 84

Tested to ASTM C 518
Unfaced
Product Designation
Nominal Density
“k” @ 75° [24°C] BTU.in/hr.sq. ft. °F
“R” value per inch of thickness**
Flame Spread
Smoke Developed
SAFB
2.5 pcf
0.27
3.7
0
0
SAFB
4.0 pcf
0.24
4.2
0
0
**R = thickness divided by ‘k’


Acoustical Performance:


Coefficeints at Frequencies Per ASTM 423

Thickness
125 Hz
250 Hz
500 Hz
1000 Hz
2000 Hz
4000 Hz
NRC
SAFB 2.5 pcf Density
2"
0.34
0.61
1.07
1.09
1.07
1.10
0.95
3"
0.51
0.99
1.18
1.03
0.99
0.96
1.05
4"
0.83
1.19
1.27
1.12
1.12
1.13
1.20
6"
1.37
1.32
1.23
1.16
1.12
1.12
1.20


Standards Compliance:

SAFB Insulation meets the following:
NFPA 101Class A rated interior finish
ASTM C 665Type I, per Federal Specification HH-I-521F
ASTM E 136Rated Non-combustible per NFPA Standard 220
ASTM C 1104Absorbs less than 1% by volume
SAFB products are approved by: New York City Board of Standards & Appeals – (under BSA 35-66-SM, 173-77-M, 249-74-SM, 34-66-SM, & accepted by MEA 207-82-M, Vol. 2)

Thermafiber
3711 Mill Street
Wabash, IN 46992
Toll Free: 1-888-834-2371
General Information Email: info@owenscorning.com
Insolutions® Email: technicalservice@owenscorning.com
Website: www.thermafiber.com | https://www.owenscorning.com/commercial
