Overview


Aluminum Doors - ADR-AL-FV-BF

NABP manufactures our NAASS bullet resistant aluminum storefront system. An integral part of this system is the ADR aluminum door. These ADR doors are available independent of the NAASS and will be built in Levels 1-8 U.L. We offer both narrow and wide stile doors. The doors will be manufactured and supplied including applicable hardware or merely prepped for hardware to be supplied by others. We stock our extrusions in mill finish, clear or dark bronze anodized. Kynar or powder coated finishes are also available.

Our ADR bullet resistant doors are generally incorporated within a NAASS aluminum storefront system. The ADR may also be purchased as a stand-alone door and frame. It has a 2” x 4 ½” aluminum frame profile. The door itself is 2 3/8” and available in narrow as well as wide stile. We have the flexibility to offer it as a full vision door or incorporate a horizontal mullion and lower opaque panel creating a ½ vision door.


See More


Specifications

Underwriters Laboratories, Inc. UL 752, 11th Edition
Rating:Ammunition:Grain:Velocity (fps):Min. - Max. No.No. Shots:
Level 19mm FMJ1241175 - 12933
Level 2357 Magnum JSP1581250 - 13753
Level 3.44 Magnum SWC2401350 - 14853
Level 4.30-06 Rifle SP1802540 - 27941
Level 57.62mm Rifle FMJ1502750 - 30251
Level 69mm FMJ1241400 - 15405
Level 75.56 Rifle FMJ553080 - 33885
Level 87.62mm Rifle FMJ1502750 - 30255
BS = 00 Buckshot, FMJ = Full Metal Jacket, JSP= Jacketed Soft Point, RS = Rifled Slug; SP = Soft Point, SWC = Semi Wad Cutter
