Overview


Metal Wall Panel Systems - Concealed Fastener Series

Concealed Fastener Series

Concealed fastener panels are available in flat, reveal, striated, and chevron profiles. The panels have a common side joint, so the designer can mix and match panel profiles throughout the facade, creating the exact desired effect. Panels may be installed vertically, horizontally, or in combination.

  • MiterSeam Corners (structurally bonded corner panels)
  • Perforated Screening Available
  • Panel coordinated louver blades


See More


Specifications

Series Features
ProfilesMore than ten profiles
FastenerConcealed clip and fastener design
ApplicationWeather tight or rear ventilated rainscreen application
Panel Depth1 1/2" (38mm) all panels
Cover Width12" - 16" and 18" - Profile Dependent
Galvalume/Zincalume Painted Steel Options18 ga / 20 ga / 22 ga
Aluminum Options.050" / .040"
Stainless Steel Options22 ga / 24 ga
Zinc Options18 ga / 20 ga / 22 ga
Natural Copper Options20 oz. / 16 oz.
ApplicationHorizontal or Vertical
