Acousti-Seal® Encore® Paired Panel System

Quick and easy setup is possible with paired panel operable partition systems, as panels are hinged together in groups of two and move in a straight line within the opening.

Acousti-Seal® Encore®

When top-of-the-line acoustic performance and premium aesthetics are desired. Acousti-Seal® Encore® raises the bar in operable partition acoustic performance with an unprecedented industry leading 56 STC along with automatic operation courtesy of the SureSet™ top and bottom seal mechanism.


Advantages of Acousti-Seal® Paired Panel Systems:
  • Hinged together in groups of two, facilitating quick, easy setup
  • Straight-line openings that do not require multiple locations or offset storage.
  • No auxiliary storage track or support required
  • Economical overhead support of straight-line track
  • Smooth operation
  • Simple automatic bottom seals for efficient operation
  • Suited for applications that require exceptional durability, acoustic control and frequent use
  • Panels are designed to be stored at either or both ends of an opening
  • Optional SOSS® invisible hinge eliminates the hinge protrusion on the panel face, adding safety and a fine line appearance
  • Optimal usage in classrooms, meeting rooms or office spaces


See More


Specifications

Acousti-Seal® - Encore®
Acousti-Seal® ModelEncore®
Acoustics - STC56, 54, 52
Panel Thickness - Nominal4.25" (108 mm)
OperationPaired Panel Manual
FrameRoll Formed & Welded 16 Gage Steel
Finish OptionsVinyl, Heavy Duty Vinyl, Carpet, Fabric, Customers Own Material, Full Height Marker/Tack Board, Uncovered
Skin/Face OptionsSteel
Maximum Opening WidthUnlimited
Maximum Height24' (7315 mm)
Hanging Weight (lbs/sq.ft.) - STC dependent8 to 12
Track Options#17, #14, #30
Pass Door SelectionSingle Matching Construction
Top/Bottom SealsTop: Automatic
Bottom: SureSet™ 2" Automatic, SureSet™ 2" Manual, SureSet™ 4" Automatic, SureSet™ 4" Manual
