SunGuard® eXtraSelective Solar Control Glass - SNX 62/27

Let natural light do what it does best with SunGuard SNX 62/27 coated glass. SNX 62/27 coated glass product offers the highest light-to-solar-gain ratio of all SunGuard coated glass. This triple silver coating is an excellent option for daylighting-making it easy to create more inviting spaces, increase occupant comfort and help achieve LEED® credits. Its neutral/green appearance stays true to your design vision while helping to gain the energy-saving performance you desire.

Product Information

Substrates
  • Clear Float/3.2-12 mm
  • UltraClear/6-10 mm
  • Green Float/6 mm
  • CrystalGray/6-10 mm
  • Gray Float/6 mm
  • CrystalBlue/6 mm
Applications
  • Facades
  • Windows
  • Doors
  • Curtain Walls
  • Roofs
  • Skylights
Manufacturing Options
  • Tempered
  • Laminated (not embedded)
  • Heat Soaked
  • Bent
  • Heat Strengthened
  • Annealed
Recommended Coating Positions
  • Double glazed: #2 or #3 surface
  • Triple Glazed: #2 surface
Maximum Size
  • 130"x240"
Edge Deletion
  • Yes
Glass Type
  • Low E
Glass Functions
  • Solar Control
  • U-Value Benefit
Fabrication Options
  • Must be used in Insulating Glass Units
Appearance
  • Clear
Product Specification

Product: SunGuard® eXtraSelective - SNX 62/27

Coating: SNX 62/27
Glass Surface Coating Position: Double glazed: #2 or #3 surfaceTriple Glazed: #2 surface
Glass Substrate: Clear Float,UltraClear,Green Float,CrystalGray,Gray Float,CrystalBlue
Available Thicknesses: Clear Float : 3.2-12 mm,UltraClear : 6-10 mm,Green Float : 6 mm,CrystalGray : 6-10 mm,Gray Float : 6 mm,CrystalBlue : 6 mm
Max. Available Size: 130"x240"
Manufacturing Options: Tempered, Laminated (not embedded), Heat Soaked, Bent, Heat Strengthened, Annealed

Key Features

  • 62% Visible Light Transmittance
  • 0.27 Solar Heat Gain Coefficient
  • 2.31 Light-to-Solar Gain
  • Available on Multiple Substrates

Glass Make-up :DoubleGlazed

GLASS: Guardian Clear Glass (North America) Glass, 1/4" (6mm) (2-SunGuard® SNX 62/27 (North America))
GAP: 10% Air, 90% Argon 12.7mm
GLASS: Guardian Clear Glass (North America) Glass, 1/4" (6mm)

Performance Values

    Visible Light

    • Transmittance (τv) 62 %
    • Reflectance outside (ρv) 11 %
    • Reflectance inside (ρv) 12 %
    • Colour Rendering Index (Ra) 93.0

    Ultraviolet

    • Transmittance UV(τuv) 6 %

    Solar Energy

    • Solar transmittance(τe) 23 %
    • Reflectance outside (ρe) 39 %
    • Solar Heat Gain Coefficient (SHGC) 0.26

    Thermal Properties

    • U-Value (Winter Night) 0.238 Btu/hr·ft²·F
    • U-Value (Summer Day) 0.209 Btu/hr·ft²·F

Calculated Values are in accordance with NFRC 2010
Manufacturer: Guardian Glass
Global and North American Headquarters
2300 Harmon Road
Auburn Hills, MI 48326
United States
Web: www.guardinglass.com
Tel: +1 248-340-1800
Email: guardianglass@guardian.com

Acoustic data: All acoustic data for your glazing configuration can be found at Glass Analytics
