Overview



Timberline® ArmorShield II Impact-Resistant Asphalt Shingles


Timberline® ArmorShield II Impact-Resistant Asphalt Shingles

Potential Insurance Savings And Extra Protection — With The Beauty of Timberline® Shingles

Compare These Benefits...

  • Potential Insurance Savings...
    Passes UL 2218 Class 4 impact test, and may qualify for insurance discounts of up to 30% or more (check with your insurance agent). Each shingle is labeled with special information needed to qualify for premium discounts according to the requirements of the Texas Department of Insurance—a standard that most hail insurers accept

  • Superior Wind Performance...
    Meets Class F wind rating from Underwriters Laboratories— the highest rating possible. Dura Grip® adhesive seals each shingle tightly and reduces the risk of shingle blow-off. Shingles warranted to withstand maximum wind gusts of up to 130 mph!*

  • Impact Resistant...
    Passes UL 2218 Class 4, UL’s toughest impact test (shingles show no evidence of cracks or ruptures on front or back immediately after passing). Compare to “standard” shingles, which may have ruptures or cracks visible on the surface or back immediately after large hail impact.

  • Exceptional Protection...
    Revolutionary design includes FLX™ formula for rubber-like flexibility and ArmorStrip™, a patent-pending puncture resistant elastomeric tape, for maximum impact resistance

  • High-Performance Design...
    Provides extra- strong Micro Weave® Core for longer life and extended durability

  • Safer...
    Class A fire rating from Underwriters Laboratories—the highest rating possible (unlike most wood shakes with a Class C fire rating)

  • StainGuard® Protection...
    Helps protect the beauty of your roof from unsightly blue-green algae

  • Peace Of Mind...
    Lifetime ltd. transferable warranty with Smart Choice® Protection (non-prorated material and installation coverage) for the first ten years**

  • Starter Strips...
    WeatherBlocker™ or Pro-Start™ pre-cut starter strip shingles provide an upgrade that can save time, eliminate waste, and reduce the risk of blow-off by tightly locking your shingles in place along the rakes and eaves

  • Ridge Cap Shingles...
    For maximum insurance savings, use only Seal-A-Ridge® ArmorShield™, UL 2218 Class 4 ridge cap shingles. They’re also a unique color match to the Timberline® ArmorShield™ II shingles

Meets Highest Impact Resistance...

The UL 2218 impact test was developed in conjunction with insurance industry leaders — and ArmorShield™ II shingles pass at Class 4 — the highest rating possible. Check with your insurance agent about potential savings on your homeowners insurance.


Timberline® ArmorShield II Impact-Resistant Asphalt Shingles

Quick Facts About The UL 2218 Class 4 "Impact" Test

The UL test...drops a 2" steel ball from 20' onto the top of a shingle to see whether the shingle cracks

Results on a standard shingle...it often has ruptures or cracks visible on the surface or back immediately after impact

Results on a special UL Class 4 shingle...impact resistant shingles show no evidence of tears, cracks, ruptures on front or back after impact

What You Should Know About This Test...

  • Forceful Impact...
    The 2” steel ball hits the shingle at 90 mph and comes to an instant stop. This is a stronger force than most hail that hits a home

  • Potential Leaks...
    Shingles that fail the impact test are more likely to allow water to leak into your home

  • No warranty improvement...
    GAF’s warranty does not cover hail damage even for shingles that pass this test

Specifications

Timberline® ArmorShield™ II Shingles

  • Passes UL 2218 Impact Test with
  • Class 4 rating (highest possible)
  • FLX™ formula for flexibility and maximum impact resistance
  • Lifetime ltd. transferable warranty**
  • Fiberglass asphalt construction
  • Heavyweight design
  • Size: 13-1/4" x 38-3/4" with 5-5/8" exposure
  • StainGuard® protection
  • Class A fire rating from UL
  • ASTM D7158 Class H, 150 mph
  • ASTM D3018 Type 1, ASTM D3161 Class F, ASTM D3462***
  • Approx. 66 Pieces/Sq.
  • Approx. 3 Bundles/Sq.
  • Approx. 264 Nails/Sq.
  • Florida Building Code approved
  • Dade County approved
  • Meets or exceeds the requirements of the Texas Dept. of Insurance
  • ICC-ES Report ESR#1475
  • CSA 123.5-98

Seal-A-Ridge® ArmorShield™ Ridge Cap Shingles

  • Passes UL 2218 Impact Test with Class 4 rating (highest possible)
  • FLX™ formula for flexibility and maximum impact resistance
  • Fiberglass Asphalt Construction
  • 5" Exposure
  • Size: approximately 12" x 12"
  • UL 790 Class A Fire Rated
  • StainGuard® Protection
  • Florida Building Code Approved
  • ICC-ES Report ESR#1475
  • Dade County Approved
  • CSA 123.5-98
  • 4 Bundles cover approximately 100 lineal feet
  • Use minimum 2 nails per piece
  • Approximately 60 pieces/bundle

* This wind coverage requires special installation. See limited warranty for details

** See ltd. warranty for complete coverage and restrictions. The word “lifetime” means as long as the original individual owner of a single family detached residence (or the second owner in certain circumstances) owns the property where the shingles are installed. For owners/structures (e.g., a church) not meeting above criteria, warranty term is 40 years.

*** Periodically tested by independent and internal labs to ensure compliance with ASTM D3462 at time of manufacture. Test results obtained after sale may vary depending on storage and roof top conditions.
