Overview


System MPLV - Plaster Exterior Façade Access Panel - Removable

The access panel consists of aluminum profiles, a Hardie Board insert and a round cylinder lock with key. Both, an outer and an inner frame of the access panel consist of four single frames, which are firmly connected due to a special welding process.

The access panel is equipped with a safety-system against accidental opening. In order to avoid accidents, this safety-system has to be secured after each opening. A joint gap of ⅛” (3 mm) is visible between outer frame and door leaf, which is equipped with an innovative brush joint (air-tight and dust- resistant water) and, in addition, with a special joint (resistant). Access panels for facades in the outer area are applicable for direct mounting into solid walls (without external wall insulation system) or for installation into a wall insulation system (foam- sealed)

  • Removable
  • Non-Rated
  • Hardie Board
  • For Exterior Facades
  • Air Tight & Dust Resistant
Advantages of using panels designed by FF Systems Inc.
  • Made in the USA
  • Fast Delivery On In-Stock Items
  • Economical Solution
  • Quick & Easy Installation
  • Solid Aluminum Frame
  • Superior Engineering & Innovative Design
  • Flush Installation In Ceilings & Walls
  • Virtually Invisible After Finished

FF Systems, Inc.

2840 Hunter Street

Fort Meyers, FL 33916

Tel: (888) 978-1808

Fax: (239) 288-4251

E-mail:Info@ffsystemsinc.com

Web Site: https://www.ffsystems.com/

545 Trillium Drive, Unit 2

Kitchener, ON N2R 1J4

Tel: (519) 896-0888


See More


Specifications

Usage & Ratings
Access Panel Design

Removable
Air Tight & Dust Resistant
Ready-To-Paint Access Door for sizes 24″ and smaller

Fire protection

Non-Rated

Usage

Plaster Exterior Facade

Model

System MPL

Measurements
Looking for measurements to plan for your project? See below for what you need.
Standard Dimensions with Hardie Board Inlay
System MPLVA(in)A(mm)B(in)B(mm)
MPLV20320382038203
MPLV3053051230512305
MPLV4064061640616 406
MPLV5085082050820508
MPLV6106102461024610
