Overview


System MWS - Masonry Access Panel - Non-Removable

The access panel consists of a welded aluminum frame and is available with 1/2″ (12.7 mm) or 5/8″ (15.9 mm) inlayed drywall and two latches. Both an outer and an inner frame assembly consists of high grade aluminum which is bonded with a special welding process. For sizes 12” x 12” (305 x 305 mm) and up the access panels are equipped with a safety system to prevent accidental opening. This safety system must be reattached if the hatch is removed.

The reveal of 1/16 of an inch (1.59 mm) is visible between the outer frame and door hatch. The concealed snap locks open the access panel when pressure is applied to the spring loaded latch side. This access panel is designed to be recessed into concrete wall systems. This panel comes with predrilled holes for easy installation.

Custom sizes:

These are custom sizes, manufactured exactly according to customer specifications.
  • Non-Removable
  • Non-Rated
  • Drywall Inlay of either ½” or ⅝”
  • For Solid Walls
Advantages of using panels designed by FF Systems Inc.
  • Made in the USA
  • Fast Delivery On In-Stock Items
  • Economical Solution
  • Quick & Easy Installation
  • Solid Aluminum Frame
  • Superior Engineering & Innovative Design
  • Flush Installation In Ceilings & Walls
  • Virtually Invisible After Finished

FF Systems, Inc.

2840 Hunter Street

Fort Meyers, FL 33916

Tel: (888) 978-1808

Fax: (239) 288-4251

E-mail:Info@ffsystemsinc.com

Web Site: https://www.ffsystems.com/

545 Trillium Drive, Unit 2

Kitchener, ON N2R 1J4

Tel: (519) 896-0888


See More


Specifications

Usage & Ratings
Access Panel Design

Non-Removable
Ready-To-Paint Access Door for sizes 24″ and smaller

Fire protection

Non-Rated

Usage

Solid Ceiling & Walls

Model

System MWS

Measurements
Looking for measurements to plan for your project? See below for what you need.
Standard Dimensions with ½” Drywall Inlay
System MWSA(in)A(mm)B(in)B(mm)C(in)C(mm)
MWS203203G127820382032.36260
MWS305305G12712305123052.36260
MWS406406G12716406164062.36260
MWS457457G12718457184572.36260
MWS508508G12720508205082.36260
MWS610610G12724610246102.36260
Standard Dimensions with ⅝” Drywall Inlay
System MWSA(in)A(mm)B(in)B(mm)C(in)C(mm)
MWS203203G159820382032.36260
MWS305305G15912305123052.36260
MWS406406G15916406164062.36260
MWS457457G15918457184572.36260
MWS508508G15920508205082.36260
MWS610610G15924610246102.36260
