Overview


System B10 - Universal Metal Access Panel - Removable

The B10 is a universal, non-rated access door. A 14 ga / 2 mm galvanized steel, formed door provides strength and rigidness, and features a screwdriver operated cam latch closure. The door is fully detachable and suitable for left- or right-hand operation. The 14 ga / 2 mm galvanized steel frame provides a smooth transition to almost any installation surface. Four riveted wall anchors ensure a quick and safe installation for any non-rated wall or ceiling application.

Capabilities

Universal, galvanized sheet metal access door can be mounted in non-rated walls and ceilings.

  • Removable
  • Non-Rated
  • Metal
Advantages of using panels designed by FF Systems Inc.
  • Made in the USA
  • Fast Delivery On In-Stock Items
  • Economical Solution
  • Quick & Easy Installation
  • Solid Aluminum Frame
  • Superior Engineering & Innovative Design
  • Flush Installation In Ceilings & Walls
  • Virtually Invisible After Finished

FF Systems, Inc.

2840 Hunter Street

Fort Meyers, FL 33916

Tel: (888) 978-1808

Fax: (239) 288-4251

E-mail:Info@ffsystemsinc.com

Web Site: https://www.ffsystems.com/

545 Trillium Drive, Unit 2

Kitchener, ON N2R 1J4

Tel: (519) 896-0888


See More


Specifications

Usage & Ratings
Access Panel Design

Removable
Universal
Screwdriver Operated Cam Latch
Metal
White Powder Coat Finish

Fire protection

Non-Rated

Usage

Ceilings & Walls

Model

System B10

Measurements
Looking for measurements to plan for your project? See below for what you need.
Standard Dimensions
System B10A(in)A(mm)B(in)B(mm)C(in)C(mm)D(in)D(mm)E(in)E(mm)
BSD200200W8203820310.1225710.122571.5840
BSD300300W123051230514.1335914.133591.5840
BSD400400W164061640618.1146018.114601.5840
BSD500500W205082050822.1356222.135631.5840
BSD600600W246102461026.1466426.146641.5840
