Overview


HSE 75 Series - Hinged Floor Access Covers

The Howe Green HSE 75 Series Hinged Floor Access Cover is ideal where regular access is required to services concealed beneath the floor. A popular solution for basement areas and plant rooms and also in public buildings (railway stations for example), where regular access is required and Health and Safety of employees, and the general public is paramount.

Manufactured by Howe Green in Ware, Hertfordshire, all covers are made to your exact specification (between stated maximum and minimum sizes) with no time or cost constraint.

Features / Benefits

Made to your specification between stated maximum and minimum sizes, with no time or cost constraint.

Any configuration of ducts and branches can be created to offer a tailor made floor access solution.

Access hatches can be linked together to provide continuous access to ducts.

Quick and easy to install ensuring minimum disruption.

Typical Floor Finishes

All types of hard floor finish - ceramic tiles, marble, terrazzo, concrete, resin, wood or parquet floors.

Performance

Medium-duty, suitable for up to 5 tonne pneumatic tyre wheel load - cars and light delivery vehicles.

Suitability

Basement areas and plant rooms that require regular access for maintenance of concealed services.

Public buildings, such as railway stations, where regular access is required and Health and Safety of employees and the general public is paramount.

Any situation where regular access to concealed services is required.

Advantages of using panels designed by FF Systems Inc.
  • Made in the USA
  • Fast Delivery On In-Stock Items
  • Economical Solution
  • Quick & Easy Installation
  • Solid Aluminum Frame
  • Superior Engineering & Innovative Design
  • Flush Installation In Ceilings & Walls
  • Virtually Invisible After Finished

FF Systems, Inc.

2840 Hunter Street

Fort Meyers, FL 33916

Tel: (888) 978-1808

Fax: (239) 288-4251

E-mail:Info@ffsystemsinc.com

Web Site: https://www.ffsystems.com/

545 Trillium Drive, Unit 2

Kitchener, ON N2R 1J4

Tel: (519) 896-0888


See More


Specifications

Performance Standards Howe Green - HSE 75
SUITABILITYInterior and exterior hard floors
LOADING5 tonne pneumatic tyre wheel load
MAX FORCE TO OPEN20kg (filled/installed correctly)
SEALOptional Double Seal
FIRE RATINGCall our sales support team on 01284 701696 for more information
Usage & Ratings
Specifications
ModelBNT/BNW/BNP
DoorBNT/BNW: 16 gauge Steel (removable) or 16 gauge Type 304 Stainless Steel
BNP: 14 gauge Steel or 16 gauge Type 304 Stainless Steel
Frame16 gauge Steel or 16 gauge Type 304 Stainless Steel
SizeMinimum: 6 inches by 6 inches
Maximum: 24 inches by 72 inches or 48 inches by 48 inches
InstallationWall or Ceiling
Flange1 inch exposed, Drywall Bead or Plaster Bead
LatchScrewdriver Cam Latch, Key Operated Cam Latch, or Mortise Lock (1-1/8 inch) Prep
HingeConcealed spring button
Pan Depth½ inch
FinishWhite Powder Coat (steel) or #4 Satin (stainless steel)
OptionsFlanges, Latches, Materials, Gaskets, Anchors
Warranty1 year
Measurements
Looking for measurements to plan for your project? See below for what you need.
