Overview


Concrete Reinforcement - Precast Connection - Groutec S

For slim panels and narrow columns, thus, necessitating a more compact design.

Precast element connection made easy!

Groutec S is a mechanical splicing designed for the connection of precast elements.

Each Groutec sleeve features a threaded end used for the connection to reinforcement at the precast factory and a cavity to perform a grout connection at site.

Groutec S is designed and manufactured in compliance with Eurocode 2, BS 8110, ACI 318, IBC, AASHTO.

Product features
  • Compatible with ribbed or deformed reinforcing bars in diameters from Ø12 to 40 mm, in grades up to 500 MPa (60 ksi).
  • Groutec S can connect bars prepared with any of Dextra thread systems: Rolltec, Bartec and Fortec.
  • At the construction site, connection is made in a few seconds by injecting/pouring non-shrink grout into the cavity.
  • Horizontal or vertical connections, in upper or lower element, Groutec can do it all!

Freedom

Our solution is compatible with grouting mortars that can be sourced close to you and at a lower cost.

Grout injection: 5s.

Make the connection in no-time by injecting non-shrink grout.

Bracing: 3 days only.

Once filled with grout, bracing around the element can be removed after only 3 days.

Main benefits

  • Engineered, tested and compatible with major non-shrink grout brands easily available on the market: Sika, Parex-Davco, Fosroc, BASF and Pozament. Reduce overall cost and simplify sourcing.

  • At the precast factory, fast and precise installation thanks to Groutec S threaded end. Take advantage of the full range of accessories available to simplify your precasting process.

  • Ideal for projects that involve slim panels and narrow columns
  • Fast: Inject or poor grout into the cavity in less than 5 seconds.Bracing can be removed after 3 days.
