Architectural Insulated Metal Wall Panels - FWGX - Vertical Profile

Formawall Dimension Series Graphix architectural insulated metal wall panels offer the ultimate design freedom. In a single panel, it creates the illusion of multiple smaller panels, reduces the number of panels required for unique project aesthetics leading to simplified installation and reduced opportunity for air and/or water infiltration.

Architectural Insulated Metal Panels

CENTRIA’s Formawall Dimension Series combines unprecedented design freedom with a variety of shapes and colors with unmatched performance. The Formawall high-performance building envelope system consolidates six wall components into one product creating distinct architectural wall profiles to match any building design.

Features and Benefits

  • Choose vertical or horizontal installation to fit your building's style.
  • Concealed clips, fasteners, and sealants with insulated metal vertical joints.
  • Panels feature a pressure-equalized side joint to help prevent water infiltration.
  • Pressure-equalized end joint available with optional Seal Plate.
  • Factory foamed in-place, minimizing the potential for gaps within the panel.
  • Panels integrate with most glass wall, window and louver systems.
  • Panel modules are available in a variety of sizes.


See More


Specifications

ThicknessThermal ValuesPanel WidthPanel Length
  • 2.5" [64mm]
  • 3"-T [76mm]
  • R-20.1 (U=0.056)
  • R-24.1 (U=0.045)
  • 10" - 40" [254-1016mm]
  • Smooth - 16' [4.9m] max.
  • Smooth striated - 20' [6.1m] max.
  • Embossed striated - 20' [6.1m] max.
  • Embossed - 20' [6.1m] max.
