C.H.I. Overhead Doors -Commercial Garage Doors - Rolling Service Doors

DOWNLOADS

Ideal Applications:

Industrial, Grain Elevators, Exterior Mounted Doors, Parking, High Security, Non-Insulated Storage, Car Wash/Corrosive Environments, Large Openings


Category: insulated roll-up doors | rubber coiling doors | rubber doors...

MasterFormat: Coiling Doors and Grilles | Overhead Coiling Doors | Special Function Doors...


View Product Details From Manufacturer


C.H.I. Overhead Doors
1485 Sunrise Drive
Arthur, IL 61911
Tel: (800) 738-5006

chiohd@chiohd.com

https://www.chiohd.com/

Find a rep/distributor

Request More Info

DOWNLOADS

Related Products

Overview


Commercial Garage Doors - Rolling Service Doors

Ideal Applications:

Industrial, Grain Elevators, Exterior Mounted Doors, Parking, High Security, Non-Insulated Storage, Car Wash/Corrosive Environments, Large Openings

C.H.I. coiling service doors are computer-engineered with time-proven principles and designs. The result is a well-built, high-performance coiling door. Choose from a variety of slat types, gauges, and operation types to specify the right rolling door for your application.


See More


Specifications

Industrial Duty: Sprung Rubber Service Door
ModelCurtainMax SizeCurtain ColorGuide Width
MR6830¼” Reinforced Rubber12’x12’Black [standard], Blue, Gray3-1/2”, 11ga. Galvanized Steel
MR6850¼” Reinforced Rubber18’x18’Black [standard], Blue, Gray5” Powder Coated Heavy Duty Steel
Industrial Duty: Insulated Service Doors (Series 6000)
ModelGaugeMax SizeInsulation/R-ValueSlat Type
618218 gauge / 24 gauge backer30'0" max std. width
24'4" max std. height		Polystyrene
R-Value 4.7		Flat
LIP Polyurethane
R-Value 6.7		Flat
620220 gauge / 24 gauge backer30'0" max std. width
24'4" max std. height		Polyurethane
R-Value 7.2		Flat
622222 gauge / 24 gauge backer24'4" max std. width
24'4" max std. height		Polyurethane
R-Value 7.2		Flat
624224 gauge / 24 gauge backer24'4" max std. width
16'4" max std. height		Polyurethane
R-Value 7.2		Flat
Industrial Duty: Non-Insulated Service Doors (Series 6000)
ModelGaugeMax SizeSlat Type
618018 gauge30'0" max std. width
28'4" max std. height		Curved
618118 gauge30'0" max std. width
28'4" max std. height		Flat
620020 gauge22'4" max std. width
24'4" max std. height		Curved
620120 gauge22'4" max std. width
24'4" max std. height		Flat
622022 gauge20’4” max std. width
20'4" max std. height		Curved
622122 gauge20’4” max std. width
20'4" max std. height		Flat
62440.050" Aluminum14'4" x 18'4"Flat
626622 gauge Stainless Steel18'4" x 20'4"Flat
Medium Duty: Non-Insulated Service Doors
ModelGaugeMax SizeSlat Type
624124 gauge12’0” x 14’4”Flat
