S-Deck Panel - Exposed Fastener Panel System

The Berridge S-Deck Panels are corrugated structural metal and can be installed horizontally or vertically with exposed fasteners. S-Deck may be curved making it ideal for use over covered walkways and shelters. This panel is available in two coverage options, two substrate options and is ideal for a variety of uses.

Materials
24 and 22 Gauge Steel
0.032 and 0.040 Aluminum

Specifications
Uses: Roof, Wall, Soffit, Ceiling, Fascia, Sheathing, Screen wall
Coverage: 32" and 34 2/3"
Finishes: Smooth corrugated
Fasteners: Exposed
Applications: Vertical on Roof; vertical or horizontal over open framing or solid sheathing for other uses
Optional: Factory curved for limited applications

Installation
Panel is available from the factory in continuous lengths to a maximum of 40’
Structural properties allow it to be utilized as a sheathing option
Estimate 130 fasteners/sq
Use foam closures to help prevent air infiltration at ridges, eaves, head walls, etc.
Use expandable foam filler tape per installation details as closure at hips and valleys
Use mastic sealant tape per installation detail at panel endlaps, sidelaps, skylights, with foam closures, etc.
