Overview


L-Panel - Soffit, Ceilings, or Fascia

The Berridge L-Panel is a versatile and maintenance free panel for use on soffit, ceilings or fascia. The prefinished panels can be used over open framing or solid sheathing. The smooth, stucco embossed and vented options allow this panel to be used throughout a project for many different applications.

Materials
24 and 22 Gauge Steel
0.032 Aluminum

Specifications
Uses: Soffit, Ceiling, Fascia, Screen Wall
Coverage: 11 5/8"
Finishes: Smooth, optional stucco emboss
Fasteners: Concealed
Applications: Vertical over open framing or solid sheathing
Pattern: Optional vee-grooves and venting

Installation
Panel is available from the factory in continuous lengths to a maximum of 40’
May be site-formed using the Berridge FP-16 Roll Former
Vented option provides 5.19 square inches of Net Free Vent Area (NFVA) per linear foot of panel (5.35 in2/ft2). (BMC does not recommend vented products in applications subject to aggressive atmospheres, marine environments or high humidity due to the corrosive nature of these environments on raw edges of steel.)
0.032 Aluminum is factory formed only
