Overview


Framing Member Components

BERRIDGE 24-GAUGE & 16-GAUGE FRAMING MEMBERS

Call a sales person now to order, or if you have a technical question, contact a staff engineer: (800) 669-0009

Materials
24 & 16 GA Steel

Specifications
Values based on 2007 North American Specification for the Design of Cold-Formed Steel Structural members, with compression flange braced against lateral buckling.
Net section properties are used for resisting moment determination and allowable shear loads.
Minimum yield strength = 40 ksi for 24 gauge shapes and 50 ksi for 16 gauge shapes (galvanized steel material).
E = 29,500 ksi.
Values are for upward and downward loads.
T.I.C. = Top in compression
B.I.C. = Bottom in compression
