Overview


Dumpster Enclosures

Architectural metal panels and light-gauge framing components for installation on concrete or asphalt pad.

Materials
24 or 22 GA wall panels
16 & 24 GA framing components

Specifications
Uses: Dumpster Enclosure
Fence Heights: 4’ 2”, 6’ 2”, 8’ 2” and 10’ 2”
Panel Widths: Vary by panel choice. Available in seven Berridge 24 gauge panels: Vee-Panel, Flush Seam, Thin Line, B-6, HS-8/HS-12, or HR-16
Finishes: Vary by panel choice
Fasteners: Interlock with concealed fasteners

Installation
Posts are spaced 10’ 2 1/2” O.C. for single posts or 10' 5" O.C. for double posts, in lieu of 8 feet O.C. with wood posts
Vertical interlocking panels with concealed fasteners
Can be installed on level or sloped applications
