Standard KD Box Lockers

Elegant and affordable, the Standard KD Locker is perfect for installation into school corridors.

Standard KD Box lockers are available in FOUR, FIVE and SIX tier models.

Features:

Body/Frame: Knockdown (KD) with 24 gauge solid body components, 16 gauge frame

Doors: 18 gauge louvered doors are standard. Plain, Secure-Air-Flow, Safety-View Plus and diamond perforated door styles are available. Continuous vertical door strike at both hinge and latch side

Handle: Projecting finger pull

Latching: Single-point thru-the-door finger pull padlock hasp

Hinges: 16 gauge continuous piano hinge

Hooks: 2-single hooks and 1-double hook is standard. 1- double hook only for triple tier and 1-double and 1 - single hook for 9" wide openings 30” and higher

Shelves: Hat shelf for single tier openings 60" and 72" high

Legs: All production KD lockers are supplied without legs unless otherwise specified.

Warranty: 2 Year


See More


Specifications

Standard:

18 gauge continuous piano hinge

Standard:

Single-point thru-the-door finger pull padlock hasp
(shown with optional padlock strike plate)

Strike Plate Upgrade:

Padlock strike plates protect finish from being marred by padlock

Max Option Upgrade:

Upgrades all body components to 16 gauge with 18 gauge back. Recommended when placing heavy items in lockers such as backpacks.
