Overview


METALWORKS Torsion Spring: 7225M14

Large-size concealed panels offer a monolithic visual with 100% downward accessibility.

Performance
  • Now, transform your images onto custom perforated METALWORKS CREATE! ceiling and wall panels for a unique aesthetic plus acoustical performance
  • Available with PUREWOOD real wood veneers in three standard finishes as well as REFLECTIONS laminates
  • METALWORKS Torsion Spring is part of the SUSTAIN portfolio and meets the most stringent sustainability compliance standards today
  • Choose from a variety of standard panel sizes that install with pre-slotted standard 15/16" suspension system
  • 48" x 48" panels are available as a premium option
  • Interior panels feature swing-down accessibility
  • For exterior applications, choose from 24 x 24 x 1-1/2" and 24 x 48 x 1-1/2" standard panel sizes
  • REFLECTIONS laminate finishes provide superior wood-look visual with printed vinyl bonded to aluminum; visuals other than the ones shown are also available
  • NRC values up to 0.90 with fiberglass infill panels (select perforation patterns)


See More


Specifications

EdgeDimensionsPerforationAcoustics
Square 15/16 in24 in x 24 in x 1-1/2 inM140.55 NRC
Performance
Acoustics
Sound Absorption (NRC) 0.55
% Open Area 5%
Fire
Fire Performance Class A
Light Reflectance 61%
Sag/Humidity Resistance Standard
Durability Soil Resistance
Impact Resistance
Washability
Scrubbability
Special Applications Library
Exterior
Accessibility
Accessibility Yes
Physical Data
Material Metal
Texture Smooth
Surface Finish Polyester paint, acrylic latex paint on acoustically transparent membrane, or vinyl-faced membrane
Shape Rectangle
Weight 0.69 PF2
Sq Ft (Sq Ft / Carton) 4
Pieces / Carton 1
ASTM Classification Type: XX, Pattern: C
Installation Method Grid (Suspended)
