Overview


V2TH Equipment Screens

V2TH Equipment Screen is a 4.75" wide tube blade vision barrier with optional blade spacings. Louver blades run horizontal with intermediate vertical supports for attachment to structural framing.

Features:
  • Made to order in sizes 12" wide x 12" high up to unlimited size
  • Made from heavy gauge 0.081" thickness aluminum extrusion
  • 5", 6", 7", or 8" blade spacing
  • 4.75" wide x 2" deep tube blade
  • Mitered outside corners for continuous blade appearance
  • Hidden Mullion joints at section breaks (partially concealed from view)
Specs:
  • V2TH5 (5" blade spacing) - 5% free area for a 48" wide x 48" high panel with a 0.95 horizontal wind load coefficient. Weight: 2.6 lbs per sq ft of louver face area
  • V2TH6 (6" blade spacing) - 21% free area for a 48" wide x 48" high panel with a 0.79 horizontal wind load coefficient. Weight: 2.3 lbs per sq ft of louver face area
  • V2TH7 (7" blade spacing) - 32% free area for a 48" wide x 48" high panel with a 0.68 horizontal wind load coefficient. Weight: 2.1 lbs per sq ft of louver face area
  • V2TH8 (8" blade spacing) - 40% free area for a 48" wide x 48" high panel with a 0.60 horizontal wind load coefficient. Weight: 1.9 lbs per sq ft of louver face area
Options:
  • A variety of metal finishes including paint and anodizing
  • Higher wind load ratings

Visibility through this model equipment screen varies between 5% and 40%, depending on the blade spacing.


See More


Specifications

V2TH5V2TH6V2TH7V2TH8
