Matrix Alpha Curtain Wall Perimeter Enclosure Grid

Curtain Wall Perimeter Enclosure Grid

Matrix Alpha security fence is a curtain wall system designed to expand to the level of site security required. Its framework structure allows the user to define the level of security needed by choosing a suitable mesh option that details the degree of delay and site visibility. Available in hot dip galvanized (HDG) or PermaCoat, the Matrix Alpha fence system is a baseline for perimeter security. Alpha’s curtain wall architecture allows for variable post spacing yielding reduced installation times.

• Hot-Dip Galvanized Option

  Available in a Galvanized or PermaCoat finish to protect from the elements.

• Meets IEEE Grounding Standards

  Ameristar was the first to successfully test steel powder coated fence to IEEE Grounding Standards.

• Curtain Wall Design

  The curtain wall architecture allows for variable post spacings and streamlined installation process.

• Adjust Visibility via Mesh Infill

  We offer a variety of mesh infill options with varying degrees of opacity ranging from 30-90% opacity.

Infill Panels:

• X-Span Mesh: .75" X #9 (Available in HDG only)
• X-Span Ultra Mesh: .5" X #13
• X-Span Modified Mesh: .5" X #13R (.188 Strand)
• X-Screen Louvered Mesh: 1.5" X #14 (Available in HDG only)
• WireWorks Mesh: .5" X 3" X 6ga & 8ga

Rails: 2" X 2"

Posts: 3" X 6" & 6" X 6"

Heights: 7' - 15' in 6in. increments

Finish

• Hot Dip Galvanized (HDG)
• PermaCoat

Post Installation

• Direct Bury
• Plated

Barbed Wire

• 3 wire available

Tech Posts

• Add an optional tech post for cameras and active security technology.

Animal Mitigation Shield

• Our system has been evaluated and recommended by an accredited herpetologist for mitigating intrusion of nuisance animals.


Spike Toppers

• Add galvanized spike toppers to the system for additional deterrence and security.
