Overview


Series 8000 Sliding Doors

Maximize the possibilities with up to eight door panels and multiple thermal breaks. Ideal for the most creative commercial and custom residential builds.

Series 8000 Sliding Door System

The Series 8000 Sliding Door System is one of All Weather’s most innovative, durable, and energy-efficient designs. Enhance how you experience the world around you by opening an entire wall with the Series 8000 sliding door’s 8 panel, 12′ tall configuration.

Held to the highest standards of quality and performance, the Series 8000 features 3” stainless steel precision bearing rollers for smooth operation, thermally strut system for increased energy efficiency and boasts robust build quality. The Series 8000 sliding door is the ideal choice for commercial projects and custom residential applications.

Features

  • Max panel height of 144” tall and min panel height of 48”
  • Max panel width of 96” and min panel width of 24”
  • Max Panel size of 70 square feet
  • Up to 8 active panels, up to 4 tracks
  • Thermally broken frame - Thermal Strut system
  • Extruded Quanex screen, Centor retractable screen available
  • Square cut corners, mechanically fastened
  • 6063 extruded aluminum age hardened to a T-6 rating for strength and durability

Frame & Sill Options

  • 2” standard sill
  • Nail On
  • Block Frame

Configurations

  • XO, OX
  • XXO, OXX, OXO, XOO, OOX
  • OXXO
  • OXXXXO

Glazing Options

  • 1” OA insulated glass
  • 1” Simulated Divided Lite (SDL) - Flat bar
  • 2 ¹⁄ 8” True Divided Lite (TDL)
  • Marine glazed
  • Enhanced Noise Reduction

Ratings & Certification

  • Up To .30 U-Values Achievable
  • Commercial Rating C30
  • Acoustically Rated


See More


Specifications

Finish Options

Class I anodized coatings are a high-performance finish used for exterior building structures and other products that are must withstand continuous outdoor exposure. Class I anodized finishes are more resistant to salt spray and the sea coast as compared to Class II

Clear Anodized, Class IDark Bronze Anodized, Class ISplit Finishes*
