Overview

Single Scissors (P) Series Lift Tables

2000# to 8000# - 24″ to 72″ travel
Platforms from 24″ x 36″ to 72″ x 144″ long

10 Year/250,000 Cycle Warranty

The P-Series lifts are our most popular series as they fit a wide array of manufacturing applications. Inquire about these industrial vertical lifts today.

SPECIAL FEATURES

These units are equipped with the patented “Platform Centering Devices”, which doubles or triples lift life.
All of the controllers are Underwriter Laboratory listed assemblies.
These units are fully primed and finished with a baked enamel finish.
The cylinders are machine grade with clear plastic return lines.
All pressure hoses are double wire braid with JIC fittings.
The reservoirs are mild steel.
These single vertical scissor lifts conform to all applicable ANSI codes.

See More

See Less

Specifications

FEATURE DETAILS

SPECIFICATION TABLE FOR SINGLE SCISSOR UNITS

Model	Travel	Capacity	Std Min Platform	Opt. Max. Platform	Maximum End	Loading Side	Baseframe Size	Lowered Height	Raised Height	Speed Sec.	Motor H.P.	Ship Wt.
P-2524	24	2500	24 X 36	48 X 60	2500	2500	24 X 36	6-1/2	30-1/2	12	1-1/2	500
P-4024	24	4000	24 X 36	48 X 60	4000	3000	24 X 36	6-1/2	30-1/2	18	1-1/2	550
P-6024	24	6000	24 X 36	48 X 60	4200	3800	24 X 36	6-1/2	30-1/2	26	1-1/2	560
PEW-2524	24	2500	36 X 36	60 X 60	2500	2500	36 X 36	6-1/2	30-1/2	12	1-1/2	650
PEW-4024	24	4000	36 X 36	60 X 60	4000	3100	36 X 36	6-1/2	30-1/2	18	1-1/2	700
PEW-6024	24	6000	36 X 36	60 X 60	4300	4000	36 X 36	6-1/2	30-1/2	26	1-1/2	710
PVW-2024	24	2000	48 X 36	72 X 60	2000	2000	48 X 36	6-1/2	30-1/2	12	1-1/2	750
PVW-4024	24	4000	48 X 36	72 X 60	4000	3200	48 X 36	6-1/2	30-1/2	18	1-1/2	800
PVW-6024	24	6000	48 X 36	72 X 60	4300	4000	48 X 36	6-1/2	30-1/2	26	1-1/2	815
P-2536	36	2500	24 X 48	48 X 72	2500	2500	24 X 48	6-1/2	42-1/2	13	2	600
P-4036	36	4000	24 X 48	48 X 72	3300	2900	24 X 48	6-1/2	42-1/2	20	2	650
P-6036	36	6000	24 X 48	48 X 72	4100	3500	24 X 48	6-1/2	42-1/2	27	2	680
P-8036	36	8000	26 X 48	48 X 72	4000	3900	26 X 48	7-1/2	43-1/2	33	2	850
PEW-2536	36	2500	36 X 48	60 X 72	2500	2500	36 X 48	6-1/2	42-1/2	13	2	765
PEW-4036	36	4000	36 X 48	60 X 72	3300	3100	36 X 48	6-1/2	42-1/2	20	2	815
PEW-6036	36	6000	36 X 48	60 X 72	4300	3100	36 X 48	6-1/2	42-1/2	27	2	845
PEW-8036	36	8000	36 X 48	60 X 72	4000	3200	36 X 48	7-1/2	43-1/2	33	2	1200
PVW-2036	36	2000	48 X 48	72 X 72	2000	2000	48 X 48	6-1/2	42-1/2	13	2	870
PVW-4036	36	4000	48 X 48	72 X 72	3300	3100	48 X 48	6-1/2	42-1/2	20	2	920
PVW-6036	36	6000	48 X 48	72 X 72	4300	3800	48 X 48	6-1/2	42-1/2	27	2	945
PVW-8036	36	8000	48 X 48	72 X 72	4000	2600	48 X 48	7-1/2	43-1/2	33	2	1350
P-2548	48	2500	24 X 64	48 X 96	2500	2200	24 X 64	7	55	19	2	730
P-4048	48	4000	24 X 64	48 X 96	3500	2800	24 X 64	7	55	28	2	830
P-6048	48	6000	24 X 64	48 X 96	3500	3000	24 X 64	7	55	38	2	850
P-8048	48	8000	26 X 64	48 X 96	4000	3900	26 X 64	8-3/4	56-3/4	44	2	1150
PEW-2548	48	2500	36 X 64	60 X 96	2500	2300	36 X 64	7	55	19	2	920
PEW-4048	48	4000	36 X 64	60 X 96	3400	3000	36 X 64	7	55	28	2	1015
PEW-6048	48	6000	36 X 64	60 X 96	3400	3000	36 X 64	7	55	38	2	1040
PEW-8048	48	8000	36 X 64	60 X 96	4000	3200	36 X 64	8-3/4	56-3/4	44	2	1600
PVW-2048	48	2000	48 X 64	72 X 96	2000	2000	48 X 64	7	55	19	2	1040
PVW-4048	48	4000	48 X 64	72 X 96	3400	3100	48 X 64	7	55	28	2	1135
PVW-6048	48	6000	48 X 64	72 X 96	3400	3000	48 X 64	7	55	38	2	1150
PVW-8048	48	8000	48 X 64	72 X 96	4000	2600	48 X 64	8-3/4	56-3/4	44	2	1800
P-2560	60	2500	24 X 84	48 X 120	2500	2500	24 X 84	10	70	28	2	1000
P-4060	60	4000	24 X 84	48 X 120	4000	4000	24 X 84	10	70	42	2	1150
P-6060	60	6000	24 X 84	48 X 120	5700	4000	24 X 84	10	70	57	2	1175
P-8060	60	8000	26 X 84	48 X 120	4000	3700	26 X 84	10	70	64	2	1450
PEW-2560	60	2500	36 X 84	60 X 120	2500	2500	36 X 84	10	70	29	2	1210
PEW-4060	60	4000	36 X 84	60 X 120	4000	4000	36 X 84	10	70	42	2	1335
PEW-6060	60	6000	36 X 84	60 X 120	5700	4400	36 X 84	10	70	57	2	1365
PEW-8060	60	8000	36 X 84	60 X 120	4000	3500	36 X 84	10	70	64	2	2000
PVW-2060	60	2000	48 X 84	72 X 120	2000	2500	48 X 84	10	70	29	2	1365
PVW-4060	60	4000	48 X 84	72 X 120	4000	4000	48 X 84	10	70	42	2	1490
PVW-6060	60	6000	48 X 84	72 X 120	5600	4500	48 X 84	10	70	57	2	1510
PVW-8060	60	8000	48 X 84	72 X 120	4000	2900	48 X 84	10	70	64	2	2200
P-2572	72	2500	26 X 102	48 X 144	2500	2000	26 X 102	10	82	31	2	1250
P-4072	72	4000	26 X 102	48 X 144	4000	2000	26 X 102	10	82	61	2	1300
P-6072	72	6000	26 X 102	48 X 144	4000	3000	26 X 102	10	82	82	2	1400
PEW-2572	72	2500	36 X 102	60 X 144	2500	2000	36 X 102	10	82	31	2	1500
PEW-4072	72	4000	36 X 102	60 X 144	4000	2000	36 X 102	10	82	61	2	1575
PEW-6072	72	6000	36 X 102	60 X 144	4000	3000	36 X 102	10	82	82	2	1675
PVW-2072	72	2000	48 X 102	72 X 144	2000	2000	48 X 102	10	82	31	2	1575
PVW-4072	72	4000	48 X 102	72 X 144	4000	2000	48 X 102	10	82	61	2	1625
PVW-6072	72	6000	48 X 102	72 X 144	4000	3000	48 X 102	10	82	82	2	1750
