Overview


Package Lifts

5 Year Structural Warranty
1 Year Electrical/Hydraulic

Package lifts are a rugged four (4) post construction that is fully assembled at the factory and can be shipped as 1 piece tilt up installation or as two (2) or three (3) piece stackable sections for quick and easy installation. The doors are typically set to open 30” above grade at each level, but can be set to open at grade level at upper landings and 3” above grade at the lower level. Mezzanine VRC lifts are well suited for automated operations.

SPECIAL FEATURES & BENEFITS

  • All of the controllers are assembled in our UL listed panel shop
  • Package lift units conform to all applicable ANSI and ASME codes
  • Motors are equipped with integral brake locks
  • Units are equipped with double chains
  • Package lift units have flattened expanded enclosures attached at the factory
  • Platforms have dual surface guides in all four (4) corners
  • Call-send-stop buttons mounted at each level
  • VRC lift platforms are equipped with load retention bars on all four (4) sides
  • Power drive units mounted in the top of each unit, other configurations are available


See More


Specifications

SPECIFICATION TABLE PACKAGE LIFT
ModelCapacityPlatform MinSize (in.) Max Low Ht (in.)Overall (in.) HeightMin WidthPlatform DepthTavel Max (ft.)Speed (FPM)HP
PAC-20020024 x 2436 x 3630 std/3 min80 + Travel *333624301/2
PAC-50050036 x 3642 x 4230 std/3 min92 + Travel **394224303/4
