ASSA ABLOY Overhead Concealed Sliding Door SL500

ASSA ABLOY SL500 - impressive performance - exceptional reliability

ASSA ABLOY SL500 overhead concealed sliding door systems create an expansive and welcoming entryway, ideal for new construction and suitable for retrofit. Featuring attractive aesthetics and robust performance, ASSA ABLOY SL500 sliding concealed doors provide an array of powerful solutions that can be trusted in even the most demanding, high-traffic environments.

The ASSA ABLOY SL500 incomparable design features fasterperformance and heavy duty anti-risers with multiple points of contact ... all housed in an attractive 4-1/2" deep header sitting flush to the jamb.

ASSA ABLOY SL500 R92 Windload - built with wind in mind

The ASSA ABLOY R92 Windload features a durable functionality & sleek aesthetics that provides defense against wind pressures up to 55 psf when door is closed and locked. Designed to accommodate a range of sizes, the SL500 R92 Windload can accommodate spaces up to 96” wide for single slide, 192” wide for bi-part and 92” high. With a wide variety of features and options, the SL500 R92 Windload is the ultimate choice for any high-traffic environment where wind protection is needed.

ASSA ABLOY SL500 EcoDoor - the sustainable choice

Further equip your ASSA ABLOY SL500 automatic sliding door with ASSA ABLOY SL500 EcoDoor optional equipment - which decrease energy costs while increasing customer comfort. Choose ASSA ABLOY EcoDoor seals, magnetic catches, hydraulic closers or U-factor insulated glass to further enhance door performance and comply with ASHRAE 90.1. Ask for your customized energy savings analysis.


ASSA ABLOY SL500 overhead concealed features
  • Attractive, shallow header sits flush to jamb or curtain wall providing exceptional aesthetics
  • Strong and powerful
  • Spanning 16’ without intermediate support
  • Dual carriage wheels standard for increased stability and performance
  • Sustainability features and enhanced options such as ASSA ABLOY EcoDoor Seals to improve air infiltration performance
  • Heavy duty door options for increased door strength
ASSA ABLOY SL500 R92 Windload Features
  • Max overall frame width: 192” bi-part, 96” single slide
  • Max overall frame height: 92”
  • Max wind pressure: 55psf
  • Full Dry Glazed System
  • Narrow Stile Design
  • Compliance with NFPA 101 life safety code
  • Grade 10 Forced Entry Resistance Rating
  • Optional insulated glass for U-value
