Mastic Home Exteriors
Ply Gem Siding Group
2600 Grand Blvd Ste 900
Kansas City, MO 64108
Toll-Free: (800) 962-6973
E-mail: support@masticsidinginfo.com
Website: http://www.mastic.com

Sweets: 07460/ALC
BuyLine: 0533

Vinyl and Aluminum Soffit

PRODUCT PRESENTATION
Give all your projects a finished look with Alcoa Vinyl and Aluminum Soffit. Ideal as fascia, wainscotting and vertical siding, this soffit works with Alcoa Ventilation Systems to help prevent heat buildup and moisture accumulation, so homes are warmer in the winter and cooler in the summer. And you can select from 6 lines and 29 colors of Vinyl Soffit — or 4 lines and 23 colors of Aluminum Soffit — for a beautiful look of customized distinction.

  • Low-Maintenance: Alcoa Soffit never needs to be painted or stained — and it won’t rust, split, crack, warp, chip, peel or flake. Plus, it resists termites and other wood-boring insects.
  • Color-Coordinated System: Guarantees that Alcoa Soffit coordinates — and complements — Alcoa Vinyl Siding, Aluminum Siding and Designer Accessories. And there is a rainbow of bright, bold and brilliant colors to choose from.
  • Registered Medallion Lifetime-Limited Warranty: If products are defective, Alcoa will repair or replace them. And the products are protected for 50 years from the date of installation — even if your client sells their home.

Vinyl Soffit
With 6 product lines and 29 colors to choose from, Alcoa Vinyl Soffit is the ideal solution for any elevation or budget.

Ventura™

  • Delivers up to 50% more ventilation space than other leading hidden vent panels
  • Superior locking system, capable of withstanding 160 mph winds
  • Available in hidden vent and non-ventilated styles

Pro-Select®

  • Extra thickness and deep grooves for the finest finished look
  • Extra strength for long-span applications
  • Special lock tightens under pressure so panels remain in place
  • Nominal .046" thickness

Pro-Tech Plus®

  • Low-gloss finish
  • Perfect for porch ceilings and carports
  • Special lock tightens under pressure so panels remain in place
  • Nominal .040" thickness

Pro-Bead®

  • Classic beaded look
  • Perfect for porch ceilings, soffit, sidewalls and wainscotting
  • Nominal .040" thickness

Trade•Markcg®

  • Economical choice for low-maintenance beauty
  • Textured finish
  • Nominal .040" thickness

Aluminum Soffit
Alcoa Aluminum Soffit features Alumalure 2000® for superior resistance to chalking, fading, UV radiation, moisture, acid rain and corrosive salt air. Plus, there are 4 product lines and 23 colors to pick from.

Traditional Select™

  • Unique V tongue-and-groove design duplicates wood-style soffit more closely than any other metal soffit system
  • 6" wide panel available (the only one in the industry) to prevent sagging
  • Available in non-ventilated and perforated styles
  • Nominal .019" thickness

Traditional™

  • Unique V tongue-and-groove design duplicates wood-style soffit more closely than any other metal soffit system
  • Available in non-ventilated and perforated styles
  • Nominal .016" thickness

Aluma-Guard™

  • U tongue-and-groove design
  • 12" profile
  • Available in non-ventilated and lanced styles
  • Nominal .016" thickness

Aluma-Guard™ Plus

  • U tongue-and-groove design
  • 12" and 16" profiles
  • Available in non-ventilated and lanced styles
  • Nominal .019" thickness

Please see all line art drawings on the Alcoa ProTools site at www.alcoahomes.com/protools.

INSTALLATION
Alcoa has designed and manufactured it’s Soffit to perform best when installed by qualified applicators. While Alcoa does not assume responsibility for installation of it’s products, it keeps installers informed on new techniques and provides detailed, step-by-step installation instructions for it’s products. Alcoa frequently updates the information with new and improved methods of application. Call 1-800-962-6973 for your copy of Alcoa’s Installation Guide today.

TECHNICAL SUPPORT
Call 1-800-962-6973.

CODE APPROVALS and CERTIFICATIONS

Alcoa Vinyl Soffit meets or exceeds the following code approvals:

  • International Conference of Building Officials (ICBO), Report No. 1478
  • Building Officials and Code Administration International (BOCA), Research Report No. 94-25
  • Metropolitan Dade County (Fla.) Board of Rules and Appeals, Acceptance No. 99-0610.3
  • British Board of Agreement (BBA), Certificate No. 00/3715
Alcoa Aluminum Soffit meets or exceeds the following code approvals:
  • International Conference of Building Officials (ICBO), Report No. 1478
  • Building Officials and Code Administration International (BOCA), Research Report No. 94-25
  • Southern Building Code Congress International Inc. (SBCCI), Report No. 9623
  • Metropolitan Dade County (Fla.) Board of Rules and Appeals, Acceptance No. 98-1119-03

AVAILABILITY and COST
Contact Alcoa at 1-800-962-6973 for the Distributor nearest you.

CARE and MAINTENANCE
Alcoa Soffit is one of the most durable building products materials available for residential applications. In most cases, normal rainfall keeps it sufficiently clean. If, however, it should need to be cleaned, Alcoa recommends the following procedures. Particular attention should be given to areas under eaves, porches, awnings and other overhangs that have limited exposure to the natural washing effect of rainfall.

  • Moderate atmospheric dirt
    Wash occasionally with clear water using a garden hose and soft-bristled brush (a long-handled, car-washing brush is ideal).
  • Heavy industrial atmospheric dirt
    Wash occasionally with a solution of 1/3 cup detergent (Tide®, for example), 2/3 cup trisodium phosphate (Soilax®, for example) and 1 gallon of water using a soft-bristled brush (a long-handled, car-washing brush is ideal).
  • Mildew accumulation
    Wash with a solution of 1/3 cup detergent (Tide®, for example), 2/3 cup trisodium phosphate (Soilax®, for example), 1 quart sodium hypochlorite 5% solution (Clorox®, for example) and 3 quarts water using a soft-bristled brush (a long-handled, car-washing brush is ideal).
  • Caulking compounds, tar and similar substances
    Apply reasonable amounts of mineral spirits directly to foreign substance and rinse area thoroughly with water.

CAUTION: Do not exceed the recommended concentrations of cleaners. To do so can cause damage to the product’s surface. Avoid skin and eye contact with the solutions, and in all cases follow manufacturers’ instructions for the use of cleaning compounds and solutions. Avoid use of abrasive-type cleaners and strong solvents. Test any cleaner on an inconspicuous area before applying to major areas. To minimize streaking, always clean from the bottom to the top and then rinse with clear water. Excessive scrubbing is unnecessary and can be harmful to the product, resulting in undesirable gloss on the finish.
