SGG SWISSFLAM® N2

SGG SWISSFLAM N2 is comprised of two or more layers of laminated safety glass separated by clear, colorless intumescent interlayers. In case of fire, the interlayers absorb the energy from the fire, limiting the temperature rise to the non-fire side, protecting people and property. Benefits include safety glazing characteristics, high performance sound reduction properties and improved U-values.

Features

  • Fire-rated for up to 2 hours (with Hose Stream)
  • Protects against fire, smoke, and radiant and conducted heat
  • Optically clear and “wire-free” aesthetics
  • Meets positive pressure requirements (UL 10c /UBC 7-2)
  • High-impact, safety-rated, laminated glass (CPSC CAT II) for use in accidental human impact safety locations
  • Can be etched/sandblasted
  • For use in interior or exterior applications
    – Insulating versions available
  • Excellent sound-reduction properties
  • Five-year limited warranty
  • Manufactured in USA
  • Complete fire-rated wall system when used with VDS Framing System

Specification
All 60, 90, 120 minute fire-and-impact safety-rated glass as designated in the drawings shall be SGG SWISSFLAM N2. Please see the attached 3-part specification or contact Vetrotech Saint-Gobain for additional information.

SGG SWISSFLAM N2 - Dimensions
Assembly Time
Rating
(min.)
Max.
Exposed
Area (sq. in.)
Max
Width
Exposed (in.)
Max.
Height
Exposed (in.)
Stop
Height
(in.)
Borrowed Lite
1" (25mm) Thickness
60 3325 95 95 5/8
1 1/2" (38mm) Thickness 90 3204 89 89 5/8
2 3/16" (56mm) Thickness 120 3288 94-5/8 94-5/8 3/4
Wood/Steel Door
1" (25mm) Thickness
60 3325 36 95 1/2
Steel Door
1 1/2" (38mm) Thickness
90 3204 89 89 5/8

General Characteristics

  • Thickness: Varies with rating and application (range from 1" to 2-3/16")
  • Weight: Varies with thickness (approx. range 11.0 –24.0 lbs/sq. ft.
  • Light Transmission: Varies with thickness (75% – 80% approx. )
  • U-Value: Contact Vetrotech Saint-Gobain for SGG SWISSFLAM-IGU
  • STC Rating: Up to 44
  • Impact Safety Rating: CPSC 16 CFR 1201 (Cat I & II) and ANSI Z97.1
  • Fire Rating: 60, 90, 120 minute

Listings

  • Tested and listed with Intertek Testing Services (Warnock-Hersey) and Underwriters Laboratories (UL), File #R22066, New York MEA #96-03-M/95-03-M/97-03-M
  • Tested in accordance with: UBC 7-2 & UBC 7-4, UL 9 & UL 10c, UL 263, NFPA 252 & NFPA 257, NFPA 251, ASTM E2010 & ASTM 2074, ASTM E-119

SGG SWISSFLAM®-45 N2
SGG SWISSFLAM-45 N2 is comprised of two layers of laminated safety glass separated by an intumescent interlayer. In case of fire, the interlayer absorbs the energy from the fire, reducing the transmission of radiant heat to the nonfire side. This permits the design a safer means of egress and separation distances.

Features

  • 45 minute fire-rated (with Hose Stream)
  • Optically clear and “wire-free” aesthetics
  • Meets positive pressure requirements (UL 10c/UBC 7-2)
  • High-impact, safety-rated, laminated glass (CPSC CAT II) for use in accidental human-impact safety locations.
  • Installs into standard fire-rated doors and frames
  • Can be etched/sandblasted
  • Excellent sound-reduction properties
  • Five-year limited warranty
  • Manufactured in USA
  • Reduces radiant heat transfer
SGG SWISSFLAM –45 N2 - Dimensions
Assembly Time
Rating
(min.)
Max.
Exposed
Area (sq. in.)
Max
Width
Exposed (in.)
Max.
Height
Exposed (in.)
Stop
Height
(in.)
Borrowed Lite
3/4" (18mm) Thickness
45 3775 84 84 5/8
Steel Door
3/4" (18mm) Thickness
45 2635 36 7-1/2 1/2
Wood Door
3/4" (18mm) Thickness
45 2397 36 70-1/2 1/2

General Characteristics

  • Thickness: 3/4" (18 mm nominal)
  • Weight: 8.0 lbs/sq. ft.
  • Light Transmission: 82% approx.
  • U-Value: Contact Vetrotech Saint-Gobain for SGG SWISSFLAM-IGU
  • STC Rating: 41
  • Impact Safety Rating: CPSC 16 CFR 1201 (Cat I & II) and ANSI Z97.1
  • Fire Rating: 45 minute

Listings

  • Tested and listed with Intertek Testing Services (Warnock-Hersey) and Underwriters Laboratories (UL), File #R14515, New York MEA #96-03-M/97-03-M
  • Tested in accordance with: UBC 7-2 & UBC 7-4, UL 9 & UL 10c, NFPA 252 & NFPA 257, ASTM E2010 & ASTM 2074, CAN4-S104 & CAN4-S106

Installation
SGG SWISSFLAM N2 should be installed only into listed fire-rated door and frame assemblies using suitable setting blocks and closed cell PVC tape, pure silicone, or ceramic glazing tape. Allow for minimum edge coverage of 3/8" and a minimum edge clearance of 1/4".

Check that opening is plumb and square. Inspect carefully before installation; do not install glass that has visible edge or surface damage. Place setting blocks (3" min) at sill, located at approximate quarter points. Check perimeter clearance and adjust setting blocks as needed. Do not block the lite so as to restrict movement due to thermal expansion; direct glass-to-perimeter frame contact should be strictly avoided.

SGG SWISSFLAM N2 is an engineered specialty fire-resistant glazing material. Certain optical and visual imperfections are inherent in the production process. These characteristics may be evaluated according to the manufacturer’s quality standards but do not impair the transparency or affect the performance of the glass in case of fire, and shall not be considered cause for rejection.

Labeling
Each lite of SGG SWISSFLAM N2 will be permanently labeled, in accordance with NFPA 80, with the product and manufacturer’s name, testing laboratory, fire rating and safety rating.

We Know Fire
Vetrotech Saint-Gobain specializes in high performance fire resisting safety glass. Advanced new technologies are used to bring clear, transparent “wire free” optics and natural daylighting into building design. Products that combine fire protection and multi-functional solutions to suit a broad spectrum of architectural and marine applications. Vetrotech Saint-Gobain is a specialist part of Saint-Gobain Glass, Europe’s number one flat glass producer and number three worldwide. www.vetrotechUSA.com
