Versa-Dek® is a suite of metal deck products that utilizes the inherent
strength and aesthetic appeal of the dovetail shape to provide architectural
and structural design communities a vast array of composite floor and roof deck
options. The Metal Dek Group® has been a leader in the development and manufacturing
of the unique Versa-Dek® shape for the past two decades.
Design Versatility
Versa-Dek® gives architects and engineers creative design options that
offer both structural requirements and aesthetic finishes. The use of Versa-Dek®
will allow a design team to design with a highly functional and versatile building
element that will also enhance construction economies of almost any project.
Versa-Dek® Floor Dek Products:
- Versa-Dek® XLS
- Versa-Dek® S
- Versa-Dek® LS (Floor)
Versa-Dek® Floor Overview
Versa-Dek® S, LS and XLS offer opportunities and options for a structurally
superior composite floor system that combines the advantages of a thin slab
system with the functionality of a finish element.
- The composite floor system offers an appealing lineal plank ceiling appearance
when viewed from the underside.
- The Versa-Wedge™ grid hanging system allows for an economical and
efficient means to hang ceilings, pipes, sprinkler systems, ducts and other
mechanical and utility equipment.
- Versa-Dek’s® dovetail shape allows the composite deck system to
achieve greater load carrying capacity in comparison to reinforced concrete
slabs of the same depth.
- Versa-Dek® acts as a permanent form for concrete and provides positive
reinforcement for the composite slab.
- Versa-Dek® is classified as a UL fire-rated, unprotected assembly for
1 to 3 hours.
- The UL ratings allow the design community to achieve the thinnest slab assemblies
of any composite deck system.
- Exceptional clear span capability provides the design community the versatility
to achieve significant open environments that complement a vast array of structural
supporting member types.
Versa-Dek® Roof Dek Products:
- Versa-Dek® S (Roof)
- Versa-Dek® S Acoustical
- Versa-Dek® LS
- Versa-Dek® LS Acoustical
- Versa-Dek® 3.5 LS
- Versa-Dek® 3.5 LS Acoustical
Versa-Dek® Roof - Overview
Versa-Dek® S and LS roof dek products are available in acoustical and non-acoustical
forms each providing a lineal plank ceiling finish while meeting all structural
load requirements for live, dead and shear. Strong and versatile, Versa Dek
can be used in various ceiling configurations including, pitched, flat, curved
and cantilever.
- The product is designed to install as a hidden fastener system that allows
for the concealment of roof overlayment material fasteners from above.
- The Versa Wedge™ grid hanging system allows for an economical and
efficient manner to hang ceilings, pipes, sprinkler systems, ducts and other
mechanical and utility equipment from the uniform dovetail seams.
- With Versa-Dek® S and LS you can achieve significant open environments
that complement a vast array of structural supporting member types.
- Versa-Dek® S and LS is available in a variety of galvanized coating
weights (high-grade corrosion resistant) steel.
- Versa-Dek® is available in a variety of paint types, paint finishes
and textures, embossed finishes and colors.
- The various corrosion system and paint system options allow the product
to be designed to meet customized market application finish demands that offer
outstanding performance.
Versa-Dek® Roof Acoustical - Overview
Versa-Dek® acoustical roof dek comes with laboratory tested NRC coefficients,
noise reductions values that range from .90 to 1.15.
For assistance with Load Tables, CAD Details, Specifications, and
other technical information, please visit our website at www.metaldek.com or
call our Dek Design Team at 888-DEKDSGN (888-335-3746).
|
