Finlandia Precut Sauna Packages
Finlandia Sauna packages are custom cut with special care and experienced craftsmanship.
We have built our reputation as "old country" Sauna builders since 1964, by believing that it takes individual attention to provide each customer with a quality piece of workmanship. Our FINLANDIA Sauna packages are custom cut with special care and experienced craftsmanship. It's the little extras that count—so we take the extra effort—such as nailing our benches from the bottom to make sure that our customers will have no worries (or burns) from protruding nails. We countersink any surface nails, and we fill any visible nail holes.

Note: In preparation for our FPC package, frame and insulate your space and follow general contractor specifications under the 3-Part Spec button on this profile. Only standard carpentry skills are needed for installation.

FPC Packages Include
PRECUT WALL & CEILING BOARDS
1" x 4" clear, certified, kiln-dried, T&G boards, cut to length of wall and ceiling for horizontal installation. Choice of 4 woods.

ASSEMBLED BENCHES of clear V.G. S4S kiln-dried 2" x 2" tops with 1/2" spacing, and 2" x 4" facing (much superior to standard 1" x 3" lightweight benches, in design and strength). Also see "Finlandia Sets the Standard for Sauna Quality" profile.

PREHUNG GLASS DOOR (FGD)
2' 0" x 6' 8" as per specs under the 3-Part Spec button on this profile. Interior casing ONLY.

ASSEMBLED HEATER FENCE
ASSEMBLED HEADREST/BACKREST for upper bench(es).

TRIM AND BASE

SUPER DEK as per specs under the 3-Part Spec button on this profile (enough for walking area of floor).

FINLANDIA OR HARVIA HEATER

PERIDOTITE STONES

CONTROL/CONTRACTOR PANEL
(if required by heater).

LIGHT wall mounted, vapor-proof.

VENTS (two sets) for installation in upper and lower wall areas.

ACCESSORIES thermometer #3444, wooden bucket #100, bucket liner #100L, wooden dipper #106/40, bathing sign.

TYPE C BUILDING FOIL

INSTRUCTIONS for building.

NAILS hot dipped, galvanized, 5p.

Finlandia Specifications For Architects/Contractors

GENERAL CONTRACTOR SPECIFICATIONS:

Framing of walls and ceiling shall be of dry Douglas Fir, construction grade no.1 or 2, 16" center. Use pressure treated plates (against concrete)

Ceiling shall be 7' 0" from finished floor to ceiling joists (16" center)

Door shall be roughed in at 26" x 82" and must open out

Insulation of walls and ceiling shall be of R11 foil faced fiberglass batts (R19 if Sauna has exterior location)

Drywall shall be 5/8" firewall (only if required by local building codes)

Added Vapor Barrier shall be of Type C construction foil over insulation or drywall—walls and ceiling (recommended as second vapor barrier)

Flooring shall be of hard surfaced, water proof type—concrete, ceramic tile, heavy-duty seamless vinyl

Floor Drain is recommended for new construction and is essential for commercial and public Saunas

Exterior Walls shall be of drywall, paneling, tile, etc. and exterior painting, door finishing, etc. shall be included

ELECTRICAL CONTRACTOR SPECIFICATIONS:

Must be licensed and bonded)

Rough-in for Sauna controls, heater, room light shall be as per FINLANDIA wiring diagram (provided with control box or in heater box)

Hookup of controls, heater, light shall be as per FINLANDIA wiring diagram (see "WallMounted Electric Sauna Heaters" and "'NewGeneration' Electric Sauna Heaters" profiles for wire size, amperage, etc.) COPPER WIRE ONLY

FINLANDIA SAUNA CONTRACTOR SPECIFICATIONS:

Walls and Ceiling shall be 1" x 4" select, certified, kiln-dried (moisture content not exceeding 11%) T&G, v joint, clear, 1" x 4" vertical grain Redwood, clear 1" x 4" Western Red Cedar, clear 1" x 4" Alaska Yellow Cedar, or clear 1" x 4" V.G. Western Hemlock. All boards shall be blind nailed with 5p galvanized, hot dipped nails, or power stapled with galvanized staples.
The following specs shall include and match one of the four woods chosen above:

Benches shall be clear S4S kiln-dried 2" x 2" tops with 1/2" spacing and 2" x 4" facing; glued and fastened with exposed nails countersunk. Bench tops shall be fastened from bottom to eliminate exposed metal

Door shall be FGD 2' 0" x 6' 8 " of vertical grain Douglas Fir rails and clear hermetically sealed, double glass, tempered (16" x 60") with casing, jamb, and threshold of Redwood

Door Hardware shall be (3) 4" x 4" butt hinges, Ives ball catch MP347B3. (2) wooden door pulls 080

Vents shall be (2) 4" x 10" louvered V10 for upper wall placement and lower wall placement. RO=3 3/4" x 9 3/4". See first diagram in "Sauna Pre-Planning" profile.

Removable Flooring shall be Super Dek interlocking 12" squares—sanitary, non-skid surface in terra cotta color—over walking area of base floor

Light shall be wall-mounted, vapor-proof Progress P5511, satin finish cast aluminum, rated for 75 watts

Sauna Heater shall be FINLANDIA model...as per cubic room footage and voltage requirements (See tables in "Wall Mounted Electric Sauna Heaters" and "'New Generation' Electric Sauna Heaters" profiles.)

Heater Fence shall be of 2" x 2" & 1" x 2" and shall be placed 2 1/2" away from Sauna heater

Temperature Control/Contactor panel shall be model...from "Wall Mounted Electric Sauna Heaters" profile

Accessories shall be...from Finlandia

Stones shall be a peridotite, heat tested, igneous type from Finland

Precut and Prefab Saunas shall be as per specifications

Warranty shall be 1 yr. on room materials and workmanship and 5 yr. limited warranty on Sauna heaters when installed according to FINLANDIA specifications and wiring information

Maintenance
FINLANDIA Sauna heaters and rooms require minimum care and maintenance. Basic household methods, including cleaning of Sauna room floor with a product such as Pine Sol, and occasional scrubbing of benches with a mild soap, is necessary for sanitary and odor-free atmosphere. When wood becomes dark or stained from perspiration, a light sanding will help to restore its beautiful appearance. Do not use sealers, paint or varnish on interior wood, as toxic vapors could be dangerous in the high temperatures of a Sauna.
NOTE: When figuring room capacities for number of bathers, allow 2' of bench space per person.

FINLANDIA SAUNA IS THE ONLY U.S. COMPANY WHICH OFFERS A CHOICE OF THE WORLD'S BEST SAUNA WOODS:

100% clear vertical grain California Redwood, clear Western Red Cedar, clear Alaska Yellow Cedar, and clear V.G. Western Hemlock (all are 1" x 4").

Our CALIFORNIA REDWOOD is 100% vertical grain (tight grain to prevent raising and slivering in the high heat), is the most fire resistant, most dry-rot resistant, most termite resistant, and does not warp.

The best known and most widely used of the West Coast cedars is WESTERN RED CEDAR. It has the most beautiful color variation, has a refreshing aroma, and is dry-rot resistant. Because it's the softest wood, it is least hot to sit on or lean against.

ALASKA YELLOW CEDAR is an exclusive white cedar with a pungent aroma. It feels almost silky to the touch, and has a beautiful appearance.

Clear WESTERN HEMLOCK is an excellent wood for people who have wood allergies—it has no aroma and no resins.
Finlandia Sauna does not use inexpensive woods such as thin knotty spruce which has a tendency to cup, shrink, warp, and crack; (and some knots come loose when the pitch and resin around them dries in the high heat of the Sauna). Many European Saunas, however, are built from knotty spruce as it has been the available wood for centuries. Knotty spruce cannot be used for benches as it gets too hot, and the knots and pitch can burn the bather; so African Abachi is imported for benches. Abachi is a clear wood and it's comfortable for sitting; but it has a peculiar, unpleasant odor. FINLANDIA uses only clear Western softwoods with the proper matching softwood for benches.

Note to architect before specifying: To be sure that your customer gets the best wood, ask for lumber samples from Sauna suppliers to compare wood qualities and thickness. Finlandia is happy to supply samples, upon request.

These specifications also apply to our Harvia Saunas.
