Knauf Insulation GmbH
One Knauf Drive
Shelbyville, IN 46176
Toll Free: (800) 825-4434
Tel: (317) 398-4434
Fax: (317) 398-3675
E-mail: info.us@knaufinsulation.com
Web site: www.knaufinsulation.us
Knauf's Batts and Blankets are thermal and acoustical products made from
highly resilient, inorganic glass fibers bonded by a thermosetting resin.
The products are available unfaced or with kraft, foil, or flame-rated FSK-25
(Foil-Scrim-Kraft) foil facings.
Knauf's Batts and Blankets are cost-effective thermal and acoustical barriers
for energy-efficient construction. Their consistent quality, low dust, and
clean-cutting resilient fibers make fabrication easy and installation fast.
The products can be used in new and retrofit wood and metal frame applications
in residential and commercial structures, as well as in manufactured housing
applications. These applications include thermal and acoustical treatments
to walls, ceilings, and floors.
In addition, High Density (HD) batts are available where optimal thermal performance
is required and space for insulation is limited. High Density Cathedral Ceiling
Batts, for example, deliver greater R-value in less space, so builders can
increase R-values and still maintain adequate space for ventilation.
Knauf QuietTherm® Insulation's excellent acoustical properties reduce
sound transmission when properly installed in partition walls, ceilings,
and floor assemblies.
Knauf Staple-Free Batts are flange-less kraft-faced batts which friction
fit between wood studs eliminating the need to staple in place. These batts
are designed for use in standard 2" x 4" wood
framed construction where the stud spacing is no more than 16" on center.
Knauf offers a full line of standard and high-density batts and blankets with
a wide range of sizes and R-values. Available unfaced, or with kraft or flame-rated
(FSK) foil facings, Knauf's residential insulation can be used for cavity
walls, floors, ceilings, attics, basements, and crawl spaces. It is highly
resilient, recovering quickly to full thickness. It also greatly reduces
the transmission of noise in the house.
This full line of standard and high-density batts and blankets for wood and
metal frame construction is available unfaced or with kraft, foil, or flame-rated
(FSK) foil facings. Knauf QuietTherm® Insulation can improve STC ratings in
wood stud construction by 3 to 5 points and in metal stud construction by
8 to 10 points, depending on the complexity of the wall configuration and
layers of insulation. Knauf's commercial building insulation can be used
for exterior and partition walls, floors, crawl spaces, and a variety of
ceiling applications.
Knauf Manufactured Housing Insulation is a full line of batts and blankets
with a wide range of R-values, lengths, and widths. It is designed to work
efficiently with pre-manufactured structures of all widths. Available unfaced
in widths up to 192" (4.88 m) or with kraft facing in widths up to 24" (610
mm), it can be used for cavity walls, floors, and ceiling applications. And
QuietTherm sound batts are available for partition walls.
Knauf's full line of retail batts and blankets comes in a wide range of sizes
and R-values, and is available unfaced or with kraft facing. Most blankets
are conveniently perforated every 94" (2.39 m) to make installation
in standard 8' walls a snap, or they can be used as-is to insulate long runs
like floor or ceiling areas. This highly resilient insulation recovers quickly
for a snug fit and assured thermal performance. Knauf's retail roll packaging
has easy-to-identify R-value and application information to help your customers
find the right product quickly.
- Excellent insulating value.
- NAHB-certified thermal performance.
- Reduces airborne sound transmission.
- Significantly improves STC ratings of wall configurations.
- Extra-wide stapling flange for faster, easier installation.
- Durable facing resists tears and is marked in one-foot increments.
- ASTM C 665*; Type I, Class A (unfaced)
- ASTM C 665*; Type II, Class C (kraft faced)
- ASTM C 665*; Type III, Class A (FSK-25 foil faced)
- ASTM C 665*; Type III, Class B (foil faced)
- GREENGUARD Certified
- GREENGUARD For Children & Schools Certified
- California Energy Commission
- Dade County, Florida
- MEA #498-90-M
- State of Minnesota
*Federal Specification HH-I-521F has been canceled and replaced by ASTM C 665.
- Unfaced and flame-rated (FSK) foil faced products do not exceed 25 Flame
Spread, 50 Smoke Developed when tested in accordance with ASTM E 84.
- Kraft faced products have a water vapor permeance of 1.0 or less.
- FSK foil faced products have ratings of .04.
- Foil faced products have ratings of .05.
- Tested and shown to be below OSHA limits.
- Diminishes to immeasurable levels within a short time frame.
- No greater than sterile cotton.
- Does not support microbial growth.
- Noncombustible (unfaced).
- Our packages feature complete installation instructions and highly visible
color coding system, which follows industry standards, making Knauf products
easy to select.
- Knauf packages are lightweight, stack without slipping, and are sized to
fit easily under floors and through scuttle holes.
- Batts are packaged in strong, white poly bags that offer excellent protection
from abuse, dust, and moisture.
- Knauf's unitized packaging combines four batt bags in one convenient banded
package, which requires less space for storage and makes loading, unloading,
and job site delivery easier.
- Standard rolls may be skip-chopped to specific lengths and are packaged in
clear poly overwrap that protects the product during shipment and storage.
- Retail rolls stack easily for display and are unitized to simplify storage
and handling.
- Retail rolls have complete DIY installation instructions and helpful product
selection guides.
R-Value |
Thickness |
Width |
Unfaced |
Kraft |
Foil |
FSK-foil |
R-11 |
3.5"
(89 mm) |
11", 15", 16", 19", 23", 24"
(279, 381, 406, 483, 584, 610 mm) |
|
|
|
|
R-13 |
3.5"
(89 mm) |
11", 15", 16", 19", 23", 24" (279, 381, 406, 483, 584, 610 mm) |
|
|
|
|
R-15HD* |
3.5"
(89 mm) |
11", 15", 19", 23" (279, 381, 483, 584 mm) |
|
|
|
|
R-19 |
6.25"
(159 mm) |
11", 15", 16", 19", 23", 24" (279, 381, 406, 483, 584, 610 mm) |
|
|
|
|
R-21HD* |
5.5"
(140 mm) |
15", 23" (381, 584 mm) |
|
|
|
|
R-22 |
6.5"
(165 mm) |
15", 16", 19", 23" (381, 406, 483, 584 mm) |
|
|
|
|
R-25 |
8.5"
(216 mm) |
15", 23" (381, 584 mm) |
|
|
|
|
R-26 |
9"
(229 mm) |
16", 24" (406, 610 mm) |
|
|
|
|
R-30HD* |
8.25"
(210 mm) |
15", 23" (381, 584 mm) |
|
|
|
|
R-30 |
10"
(254 mm) |
11", 16", 19", 24" (279, 406, 483, 610 mm) |
|
|
|
|
R-38HD* |
10.25"
(261 mm) |
15", 23" (381, 584 mm) |
|
|
|
|
R-38 |
12"
(305 mm) |
16", 24" (406, 610 mm) |
|
|
|
|
*HD-High Density Insulation
R-Value |
Thickness |
Width |
Unfaced |
Kraft |
Foil |
FSK-Foil |
R-8 QT** |
2.5"
(64 mm) |
16", 24"
(406, 610 mm) |
|
|
|
|
R-11 QT** |
3.5"
(89 mm) |
16", 24"
(406, 610 mm) |
|
|
|
|
R-13 QT** |
3.5"
(89 mm) |
16", 24"
(406, 610 mm) |
|
|
|
|
R-19 QT** |
6.25"
(159 mm) |
16", 24"
(406, 610 mm) |
|
|
|
|
**QT-QuietTherm Insulation
R-value |
Thickness |
Width |
Unfaced |
Kraft |
Foil |
FSK-Foil |
R-7 |
2.25"
(64 mm) |
15", 23", 48", 60", 72", 84",90", 144", 164", 168"
(381,
584, 1219, 1524, 1829, 2134,2286, 3658, 4166, 4267 mm) |
|
|
|
|
R-11 |
3.5"
(89 mm) |
15", 23", 48", 60", 72", 84",90", 144", 164", 168"
(381,
584, 1219, 1524, 1829, 2134,2286, 3658, 4166, 4267 mm) |
|
|
|
|
R-14 |
4.5"
(114 mm) |
15", 23"
(381, 584 mm) |
|
|
|
|
R-19 |
6.25"
(159 mm) |
15", 23", 60"
(381, 584, 1524 mm) |
|
|
|
|
R-30 |
10"
(254 mm) | 16", 24"
(406, 610 mm) |
|
|
|
|
|
