EPDM Thermoset Single Ply Roofing Systems

Single ply membranes entered the U.S. low-slope roofing industry during the 1970s. There are two basic types: thermoplastic (plastic polymers) and thermoset (rubber polymers).

The material used by JM Roofing Systems for its thermoset single ply membrane is called EPDM (ethylene propylene diene monomer). The polymer allows the membrane to become quite rubber-like, deforming under stress and recovering its original shape when the stress is removed. This gives the membrane superior weatherability through a wide range of temperature fluctuations. The material also demonstrates superior ozone resistance and is quite resistant to ultraviolet rays, requiring no coatings.

UltraGard EPDM membranes are large, factory-fabricated sheets spliced together on-site with compatible adhesives or tapes, offering time-saving economic advantages and clean application. The EPDM sheets may be loose-laid and ballasted, mechanically attached with fasteners, or fully adhered. The complete product line includes adhesives, sealants, flashing materials, coatings and accessories to provide a single-source systems approach to the roofing assembly.

UltraGard EPDM single ply systems are adaptable to many sizes and shapes of roofs, new or existing. They are recommended for slopes not exceeding two inches per foot for ballasted, and not exceeding six inches per foot for adhered and mechanically attached. All three application methods are suitable for new construction, retrofit or complete tear-off.

For additional information, contact the Regional Technical Services Manager who can be reached through the JM Regional Sales Office nearest you, or the Technical Services Specialists at the Guarantee Services Unit.

EPDM Single Ply Roofing Components

Membranes

  • UltraGard Nonreinforced EPDM .045
  • UltraGard Nonreinforced EPDM .060 FR
  • UltraGard Nonreinforced EPDM .060 FR XT
  • UltraGard Reinforced EPDM .045R XT
  • UltraGard Reinforced EPDM .060R XT
  • UltraGard EPDM .060 (White)


    • Flashing

  • UltraGard EPDM Flashing
  • UltraGard EPDM Peel & Stick Flashing
  • UltraGard EPDM Peel & Stick Pipe Flashings
  • UltraGard EPDM Metal/Membrane Flashing


    • Roofing Cements

  • UltraGard EPDM Lap Cement
  • UltraGard EPDM Bonding Cement


    • Caulking and Sealers

  • UltraGard EPDM Lap Caulking
  • UltraGard EPDM Sealing Mastic
  • UltraGard EPDM Pourable Sealer
  • UltraGard EPDM Nite Stop


    • Tapes and Strips

  • UltraGard EPDM Seam Tape
  • UltraGard EPDM Peel & Stick Sealing Strip
  • UltraGard EPDM Peel & Stick Cover Strip
  • UltraGard EPDM Reinforced Termination Strip (RTS)
  • UltraGard EPDM Reinforced Termination Strip (RTS) with Tape


    • Anchor Discs and Bars

  • EPDM Anchor Discs
  • EPDM Termination Bars
  • EPDM Anchor Bars


    • Primers and Cleaners

  • UltraGard EPDM Tape Primer/Wash
  • UltraGard EPDM Splice Cleaner


    • Coatings

  • UltraGard EPDM Color Coating (for fully adhered only)


    • Accessories

  • UltraGard EPDM Walkway Pads


    • Sources For Full Information

    For complete information and specifications on Built-Up, Modified Bitumen and Single Ply roofing products and applications, please refer to the JM web site, www.jm.com. For information relating to Single Ply products refer to the JM UltraGard Single Ply manual (RS-8100). Contact the Regional Technical Services Manager who can be reached through the JM Regional Sales Office nearest you, or the Technical Services Specialists at the Guarantee Services Unit.
