08520 Aluminum Windows

Projected Windows


New Overview Image

AA® 900 ISOWEB® Window
Weathertight versatility. High thermal performance.

  • Improved thermal performance developed specifically for climates subject to temperature extremes
  • Unique corner joinery provides consistent "picture frame" sightlines
  • Two-color finish option available
  • Ideal for health care, condominiums — anywhere comfort is paramount


Aluminum Windows Img1

7225 Non-Thermal, Heavy Commercial Window
For High performance in a non-thermally broken Window system.

  • Available as projected, casement, top hinged and fixed
  • Tested for Heavy Commercial and Architectural Window Performance Class and Grade
  • 2-1/4" frame depth
  • Optional dual glazing with or without Venetian blinds
  • Large and small missile hurricane impact and cycle tested (fixed over project out)


Aluminum Windows Img2

8225TL Thermal Windows
For high performance in a thermally broken window system

  • Available as Projected, Casement, Top Hinged and Fixed
  • Tested for Performance Class and Grade of HC90 and AW90
  • 2-1/4" (57.2) frame depth and 0.090" nominal wall thickness
  • Overlap Vent Design
  • Patented ISOLOCK® Thermal Break mechanically and adhesively bonds the thermal break material to the aluminum frame and prevents dry shrinkage.
  • Cast white bronze cam locks and keepers
  • Optional dual glazing with or without Venetian blinds
  • Optional factory glazing


Aluminum Windows Img8

526 ISOPORT® Windows
High performance Ribbon Window

  • 14.6 mm ISOPORT® glass-reinforced nylon 6/6 thermal break provides:
    -  Improved condensation resistance and thermal transmittance performance capability
    -  Rigid profile with composite structural performance
    -  Exterior / interior finish options
  • Meets or exceeds the highest performance levels of CSA standard CAN/CSA-A440 windows
  • Sash features mitered and clip, adhesive, stake joinery to provide rigid and weather tight corners
  • Operating sash uses tubular extrusions
  • Factory fabricated and assembled
  • Optional full rain screen capability
  • Accommodates 25 mm sealed glazing units
  • Glass installed and replaced from interior
  • Exterior pre-shim butyl glazing tapes
  • Interior EPDM rubber glazing gaskets
  • Lock-in glass stop
  • Optional insect screens


Aluminum Windows Img9

5500 ISOWEB® Window
Highest thermal performing fixed for punched and strip openings

  • Meets or exceeds performance standards of ANSI/AAMA and 101/CAN/CSA440
  • 4" (101.6) frame depth
  • Cast white bronze cam locks and keepers
  • Flush appearance with extreme frontal placement of glass
  • ISOWEB® glass reinforced nylon thermal break provides low thermal transmittance, high condensation resistance and eliminates dry shrinkage


Aluminum Windows Img10

5525 ISOWEB® Window
Highest thermal performing fixed  for punched and strip openings

  • Meets or exceeds performance standards of ANSI/AAMA and 101/CAN/CSA440
  • 5" (127) frame depth
  • Cast white bronze cam locks and keepers
  • Flush appearance with extreme frontal placement of glass
  • ISOWEB® glass reinforced nylon thermal break provides low thermal transmittance, high condensation resistance and eliminates dry shrinkage
  • Vented rain screen design and two-color option


*** Overview Image

Hung / Sliding Windows
AA® 3350 ISOPORT® Window
Enhance Your Views with Exceptional Value and Performance

  • Available in Architectural Window and Commercial Window class and grade
  • Window is highly versatile, leading the way in thermal performance at a competitive price
  • Available as fixed, single hung, or double hung
  • 3-1/2-inch frame depth
  • The unique shape of the polyamide thermal break enhances the performance of the window by maintaining the continuity of the thermal break throughout the window frame and sash
  • Class 5 heavy duty balances
  • Factory silicone glazed
  • Optional insect screens


Aluminum Windows Img11

8400TL Heavy Commercial
For high performance and design flexibility

  • Available in fixed, offset fixed, single hung, double hung and horizontal sliding.
  • Tested for performance class and grade ranging between HC/AW70 to HC/AW100
  • 4" (101.6) master frame depth
  • Available with standard face or putty glaze replication
  • Patented ISOLOCK® thermal barrier
  • Master frame barrier consisting of a two-part, chemically curing high density polyurethane, which is mechanically and adhesively bonded to the aluminum
  • Sash barrier consisting of a two-part, chemically curing high density polyurethane in conditioned thermal pockets, which is mechanically and adhesively bonded to the aluminum.
  • Factory Glazed


Aluminum Windows Img14

Ribbon Windows
516 ISOPORT® Window Framing
High performance Ribbon Window

  • 14.6 mm ISOPORT® glass-reinforced nylon 6/6 thermal break provides:
    - Improved condensation resistance and thermal transmittance performance capability
    - Rigid profile with composite structural performance
    - Exterior / Interior finish options
  • Meets or exceeds the highest performance levels of CSA standard
  • CAN/CSA-A440 windows
  • Seamless coupling mullion features unbroken weather joint on exterior surface
  • Provision for thermal movement
  • Simple joinery with overlapping flanges for economical construction and good weathering capability
  • Optional full rain screen capability
  • Accommodates 1" (25 mm) sealed glazing units
  • Glass installed and replaced from interior
  • Exterior pre-shim butyl glazing tapes
  • Interior EPDM rubber glazing gaskets
  • Lock-in glass stop
  • Open-in frameless vent option
  • Companion open-out or open-in vent inserts available
  • Accepts 512 Ventrow ISOLOCK® Ventilator inserts


Aluminum Windows Img16

518 ISOPORT® Window Framing
High performance Ribbon Window

  • 14.6 mm ISOPORT® glass-reinforced nylon 6/6 thermal break provides:
    - Improved condensation resistance and thermal transmittance performance capability
    - Rigid profile with composite structural performance
    - Exterior / Interior finish options
  • Meets or exceeds the highest performance levels of CSA standard
  • CAN/CSA-A440 windows
  • Provision for thermal movement
  • Simple joinery with overlapping flanges for economical construction and good weathering capability
  • Optional full rain screen capability
  • Distinctive "Top Hat" accent feature
  • Accommodates 25 mm sealed glazing units
  • Glass installed and replaced from interior
  • Interior EPDM rubber glazing gaskets
  • Lock-in glass stop
  • Open-in frameless vent option
  • Companion open-out or open-in vent inserts available
  • Accepts 512 Ventrow ISOLOCK® Ventilator inserts


PG 123® ISOWEB® Framing
Responding to the need for quality control, simplified fabrication and faster installation, Kawneer has designed PG 123®, a ribbon window and multi-lite punched opening system with preglaze capability, labor-savings and unit construction.

The system is structural silicone glazed with captured head and sill cans, and intermediate horizontals.

Key Features Include:

Economy


  • PG 123® may be supplied in stock lengths or factory fabricated
  • In addition, the system can be pre-assembled and pre-glazed under controlled shop conditions that save time compared to field construction
  • Screw spline joinery, with square cuts and no miters or notching, reduce fabrication time
  • Pre-glaze units are installed from the interior of the building to minimize weather delays and reduce the need for scaffolds and lift equipment



Performance

  • Incorporates the ISOWEB® glass reinforced nylon thermal break that provides improved condensation resistance and reduces thermal transmittance
  • Fully pressure equalized with a rain screen gasket to eliminate the exterior seal between glazed units
  • PG 123® is fully tested to appropriate AAMA, ASTM & CAN/CSA A-440 standards for air, water and structural performance


Aesthetics

  • The ribbon window system is structural silicone glazed vertically with optional applied covers to give a four-sided captured appearance
  • Optional vertical covers provide a clean, monumental appearance without sight line build up for building owners who prefer more traditional aesthetics
  • The ISOWEB® Thermal Break offers dual finish options, allowing different interior and exterior color finishes
  • Accommodates a one-inch infill with ¼ inch adaptors for spandrel applications


Aluminum Windows Img18

Concealed Vents
GLASSvent (for Storefront Frames)
Visually Frameless Windows
For use with Trifab® 400, Trifab® VG 450, 451 & 451T, and EnCORE® Framing Systems

  • Available as a Project-Out or Outswing Casement Window
  • No Exterior Framing Sightline Buildup
  • Suitable for Retrofit or New Construction
  • Performance Tested for a Class and Grade of HC40 and HC70
  • Thermally Improved Flush Vent Design
  • Structural Silicone Glazed for 1/4" (6.4) and 1" (25.4) infill
  • Thermally improved
  • Cast White Bronze Locking Hardware
  • Concealed Stainless Steel 4-bar Hinges
  • Optional Hardware Available


Aluminum Windows Img19

GLASSvent (for Curtain Walls)
For use with 1600 Wall System®1 , 1600 Wall System®2 , 1600 Wall System®3 , 1600 Wall System®4 , 1600 Wall System®5 , 2250 IG, and 2250 LR Curtain Wall Systems

  • Available as a Project-Out or Outswing Casement Window
  • No Exterior Framing Sightline Buildup
  • Suitable for Retrofit or New Construction
  • Performance Tested in Accordance with AAMA 501 at 50 psf
  • Thermally Improved Flush Vent Design
  • Structural Silicone Glazed for 1/4" (6.4) and 1" (25.4) infills
  • Cast White Bronze Locking Hardware
  • Concealed Stainless Steel 4-bar Hinges
  • Optional Hardware Available


Aluminum Windows Img20

512 Ventrow ISOLOCK® Ventilator
Thermally broken, insulated, modular, insert ventilator

  • Rain screen element over ventilator prevents direct rain contact with the ventilator weathering
  • Air movement results from natural air circulation
  • Highly effective ventilator seal
  • No operating hardware required
  • Finger tip control of opening and closing
  • Visually the same, either open or closed
  • Can be installed in any Kawneer fixed frame with a depth of 4" (101.6) or more
  • Optional keyed lock
  • Meets the highest performance levels of CSA Standard CAN / CSA-A440
  • Factory Fabricated
