CoreFlex^™ Thermoplastic Waterproofing Membrane

The CoreFlex system by CETCO offers Building Owners, Specifiers, and Contractors reliable waterproofing protection for below-grade foundations, plaza decks and greenroof applications. CoreFlex features a welded thermoplastic membrane with the industry's heaviest reinforcement plus Active Polymer Core Technology that activates and seals a water breach – automatically and reliably.

• APC Technology for Active Sealing – Active Polymer Core Technology activates and seals water breach through the thermoplastic membrane – automatically and reliably


• Elvaloy-KEE Based Membrane – CoreFlex's integrated polymer, Elvaloy-KEE, provides enhanced thermoplastic membrane properties and durability


• Superior Reinforcement – Manufactured with knit polyester fabric, CoreFlex exhibits superior tensile and tear strengths over fiberglass and lighter weight polyester reinforced membranes


• Monolithic Membrane – Our coating process completely embeds the reinforcement and creates a monolithic membrane that won't delaminate


• Welded Seams – CoreFlex's seams are fully fused, watertight and stronger than the original membrane


• Extremely Low Permeability – CoreFlex has an extremely low water vapor transmission that qualifies it as a Class A Vapor Retarder per ASTM E1745


• Chemical Resistance – The Elvaloy-KEE based thermoplastic membrane provides superior resistance to a broad array of chemicals typically found in below-grade soil conditions


• Methane Barrier – CoreFlex is certified with the City of Los Angeles for both Waterproofing and Methane Barrier


• Excellent Hydrostatic Resistance – CoreFlex has been successfully tested to resist 231 feet (100 psi) of hydrostatic pressure per ASTM D5385

Applications

CoreFlex is ideal for:

• Plaza Decks
• Underslab
• Walls
• Green Roofs
• Restoration
• Tunnels

Restoration

CoreFlex's KEE based thermoplastic membrane, in conjunction with the APC, is engineered to resist common construction contaminants. It provides maximum resistance to standing water, oils, chemicals, salt, as well as asphalt and tar based materials. This advanced technology and dual membrane design allows for minimal demolition and enables CoreFlex to be installed over most adhered existing waterproofing membranes. This offers huge savings in time, cost and building disruption!

• Diminishes costs associated with surface prep and demolition
• Faster dry-in time than other systems allows for quicker project turnaround
• Dramatically reduced exposure of finished space protecting the structure from weather related damage
• Dual waterproofing membrane combines active and passive waterproofing providing unbeatable protection from water ingress
• Heat welded seams provide fully fused, water tight protection

CETCO's HydroShield Quality Assurance Program protects your structure from water ingress with sound design guidance, quality waterproofing products, proper installation, as well as qualified independent inspection programs.

The HydroShield Quality Assurance Program provides:

• Design Assistance
• System Review
• Job-Specific CAD Details
• Approved Applicators
• Independent Inspection
• Financial Assurance

CETCO's commitment to quality allows you to rest easy knowing your structure is protected by the long term performance you expect from your waterproofing system and backed by the industry leading, no dollar limit HydroShield Quality Assurance Program. Remember, If it's worth building, it's worth protecting.
