Somfy ILT II - Motor and Control Network

Somfy ILT II - Motor and Control Network

Somfy ILT II

  • General Information
    Easy to wire – standard modular plug and wire / Cat 5
    Economical wiring
    Limits set at the switch vs. at the motor
    Interfaces w/ most commercially available control systems
    Motor can be instructed to move to any position within its limit range
    Motor can be queried for current position
    Embedded Com port for bidirectional data communication

  • Features
    Each motor is individually
    addressable (3 byte address)
    16 preset intermediate positions
    16 groups (each w/ 3 byte address)
    Movements – limits, IP, nearest IP, percent, encoder position Tilt function available
    Node name (32 characters)
    Prioritized lock out of motors, groups and controls
    Read / write all parameters (address node, name current location)
    Native IR operation (for off network operation)
    Native RF operation (for off network operation)
    Native dry contact operation (for off network operation)
    Backward compatible with all ILT products


Somfy ILT II - Motor and Control Network

  • Benefits
    Embedded electronics – no external motor controllers
    Encoder based positioning – more accurate than timing
    Bus line communication
    Bus line connected controls
    1000’s of motors and controls on a single network
    No routers required
    Lower cost installation
    Faster troubleshooting / faster configuration

  • Controls
    Keypads, Contact closure interface
    IR (IRT 803 compatible)
    RF (RTS compatible)
    Wind, sun and occupancy sensors
    RS232 / RS422 interface
    BacNet IP interface / Modbus IP interface
    PC / PDA web internet
