Overview



Parasol Cellular Shades

Parasol Cellular Shades

Parasol FR Cellular Shade fabrics meet all requirements of NFPA 701 small scale flammability testing for commercial applications. There are three fabric types - 3/4” semi opaque, 3/4” opaque and 3/8” semi-opaque. Each fabric type has four colors available - Dune, Marble, Snow and Soft White.

Energy efficient cells are constructed of a permanent flame-resistant textured, non-woven polyester formed into opaque 3/4” and 3/8” hexagonal cells in stacked tubular construction. Each cell is an independent piece of fabric and contains a metallized polyester film core.

Cordless Accu-Rise® (3/4” fabrics only) or clutch operated ContinuumTM Continuous Cord Loop System both provide a child safe option. Motorization is the ultimate child safety choice. A fabric covered headrail is standard and conceals the white headrail color.

A variety of shade types are available including Top Down/Bottom Up on Continuum or Accu-Rise or Two Shades on One Headrail for Continuum or Cordlock shades. Other options include: Specialty Shapes, Glissade Vertical Cellular Shades (3/4” only) and Skylight shades.

Parasol FR Cellular Shades are GREENGUARD Gold Certified and have a Lifetime Limited Warranty.

Dimensional Guidelines

Continuum Continuous Cord Loop System

Width
   Minimum ...................................................12"
   Maximum ................................................174"

Height
   Minimum ...................................................24"
   Maximum:
       3/4" Semi -Opaque ...........................144"
       3/4" Opaque .......................................144"
       3 / 8"Semi-Opaque ..........................138"

Maximum Area
    3/4" Semi -Opaque .......................150 sq ft
    3/4" Opaque ...................................120 sq ft
    3/8" Semi -Opaque .......................130 sq ft

NFPA 701 FR Test Results

For a complete selection of the FR materials, visit the Materials Library at www.lafvb.com:

  1. Select Product Type: Shades
  2. Select Type: Flame Retardant
  3. Select Product Name: Parasol Cellular Shades

            NFPA 701 FR results are available for download by clicking on the thumbnail
