Extruded Aluminum Radiant Ceiling Panels

Extruded Aluminum Radiant Ceiling Panels

Aluminum Extrusion (AXO) ceiling panels are constructed of 5",6",8",or 9" wide extruded aluminum strips of approximately 0.10" overall thickness. Active strips have a .505" ID copper tube inserted into a "U" shaped channel on the back of the extrusion. This channel is formed more than halfway around the copper tube for increased thermal conduction and to eliminate any separation of the copper tube and the aluminum strip.

The small gap between the rolled-over lips of the aluminum extrusion provides easy access to the copper tube. This feature means Extruded Panels are ideally suited to situations where field modification of the panels is likely.

Tube ends will accept a 3/8" Type "L" soft copper tube without the need for fittings.

Standard panel maximum length is 12 feet (lengths up to 16 feet can be fabricated on special request). Panels can be constructed in any width utilizing any combination of 5",6",8" and 9" wide extruded aluminum strips.

Matching, non-radiant (inactive) panels can be provided on request.

AXO Panels are factory assembled and can be finished in a large variety of standard or custom ways including curving panels along the length. (Please contact Aero Tech regarding curving guidelines).

Face configurations are available in V-groove, fluted and smooth.

Note

These extruded aluminum radiant panels are available in standard pressure drop and low pressure drop models – contact Aero Tech Manufacturing for additional engineering information.
